SPECIFICATIONS
Product name Ultra-Low Temperature Freezer
MDF-U700VX
Medical purpose Storage of cells, organs, DNA, plasma.
External dimensions W 1010 mm x D 870 mm x H 2010 mm
Internal dimensions W 870 mm x D 600 mm x H 1400 mm
Effective capacity 728 L
Exterior Painted steel
Interior Painted steel
Outer door Painted steel
Inner door ABS resin panel with stainless frame, 2 doors
Shelf Stainless steel, 3 shelves (adjustable)
Inner dimension: W 848 mm x D 533 mm Load: 50 kg/shelf
Access port 17 mm diameter, 3 locations (back x 1, bottom x 2)
Insulation Vacuum insulation panel + Rigid polyurethane foamed-in place
Compressor A side; Hermetic type, Output: 1100 W
B side; Hermetic type, Output: 1100 W
Evaporator Tube on sheet type
Condenser Finless tube type
Refrigerant HFC mixed refrigerant
Temperature controller Microcomputer control system
Temperature display Digital display
Thermal sensor Platinum resistance (Pt 1000Ω)
Alarm High-temperature alarm, Low-temperature alarm, Power-failure alarm, Door alarm,
Sensor abnormality, Condenser temp. abnormality, Fan motor abnormality,
Compressor temp. abnormality, Cooling circuit abnormality
Remote alarm contact Allowable contact capacity: DC 30 V, 2 A
Battery Nickel-metal-hydride battery, DC 6 V, 1100 mAh, Auto-recharge
Accessories 2 keys, 1 scraper, 1 stick for frost removal
Weight 375 kg
Optional components Temperature recorder (MTR-G85C), (MTR-85H)
Inventory rack (IR-220U, IR-224U)
Interface board (MTR-480, MTR-L03)*
Back-up cooling kit (CVK-UB2): LCO
2
Small inner doors (MDF-7ID)
Design or specifications are subject to change without notice.
Refer to the updated catalogue when ordering an optional component.
*: For the data acquisition system MTR-5000 user only. Contact our sales representative or agent for
purchase.
