Philips 19PFL5522D - Colour Television Module Auo (Acer Unip.) LCD 2 K7

Published by MW 0767 BU CD Customer Service Printed in the Netherlands Subject to modification EN 3122 785 16900
©
Copyright 2007 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Colour Television Module
AUO (ACER UNIP.) LCD 2k7
T260XW02V400, T260XW02V401
T296XW01V0, T296XW01V3
T315XW01V5
T370XW01V1
Contents Page
1. Technical Specifications, Connections, and Chassis
Overview 2
2. Safety Instructions, Warnings, and Notes 3
3. Directions for Use 4
4. Mechanical Instructions 5
5. Service Modes, Error Codes, and Fault Finding 14
6. Block Diagrams, Test Point Overviews, and
Waveforms 15
7. Circuit Diagrams and PWB Layouts 15
8. Alignments 15
9. Circuit Descriptions, Abbreviation List, and IC Data
Sheets 15
10. Spare Parts List 15
11. Revision List 15
