the bent curved section of the mold touches.the curved part 90º of the template Furthermore,
the position of the stop bracket 10 must be such that the free end of the leaf spring is as close as
possible to the main shaft and the com. disk is slid, but without hitting it. The preload of the leaf
spring must be sufficient, to ensure a good latch. Now tighten the two fastening screws of the locking
bracket/clip again.
Now the template (see Fig. 4a) can be tightened around the main shaft as shown in the
figure The locking bracket must be moved by pushing such in such a way that the roller
(8) presses against the center of the cam 4e and at the same time the point cu nose
(3) touches the curved part 90 ° of the template. in such a way that the free end of
the leaf spring is moved as close as possible to the main axis and the control disc,
however without touching them.The forward tension of the leaf spring must be
sufficient to guarantee a good
Finally, tighten the two fixing screws of the brake caliper
P14a
...WHERE DOES THIS BELONG?
Check: Attach the control disc to the main shaft (start and turn the turntable clockwise[in the normal
run direction ] by hand) During the rotation, which makes the control disc , the pivot point of the
driver (127) passes the lock bracket, after which the part of the carriage does not If necessary, the
locking clip must be slightly bent back (at the free end of the leaf spring), and the cam on the oschiji
command must slide smoothly into the opening of the leaf spring and the latching may still be
complete.
.........................................................................
4. Staging of the start-stop position/ mode
A. Control disc in home/rest position, gramophone sensor arm on
turntable and plate presser on the shoulder of the centers now fitted. The short end of the
starting spring (23) must move freely in the rest and stop position of the switch in the
fastening position of the switch strip (30).
this should be achieved if necessary. Curving if needed.
B. The long end of the starting spring must start at the
outermost position on the CONTROL DISC drive.
The pressure may not exceed 75 grams. the term "extreme position" is understood to mean that the
tangent point lies on the main axis. Here, the bent portion of the starting spring touches the
right-angled portion of the carrier. The bend of the starter spring must be
33
