P17
• The role marked "ordered
8. Set the speed
Use should be made of the Stroboscopic disc included in this documentation.
See also p13...
A. Set 78 rpm
Connect mains voltage. Place a 30 cm plate on the turntable and use the stroboscopic disc. Place
the P.U.arm on the disc/plate.
You can now switch on with the screw A fig.7) at * 78 RPM
get fixed.
B. Set 33 1/3 turns
The same applies as under A,
but now the stop is fixed with screw (B).
Adjust 45 rpm Place the trade in the recess of the lock spring. With the 2
nd
screw (C) [B ??]
C. 45 rpm adjustment.
Bring the handle to middle recess of the stop spring. With the. 3rd lever screw
(c) and the stop spring can then be fixed in the desired position.
39
