Note: item ’A’ fig 9 secures here [left end ,top] w 2 screws
XII THE TURNTABLE REMAINS RUN AFTER THE PU ARM
IS RETURNED ON THE SUPPORT ON THE HEART SWITCH.
The position of the bracket net roll (1) is too low. Here, the am of the switch is not pushed down
sufficiently. The screw (2) by turning on the bracket sliding it toward the top. Dearna tighten the screw
again. It should also be taken to ensure that the caster can rotate easily. Add a drop of oil if necessary.
R13568
55
