20040914 1-18-9 E9480EL
●
R569 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R571 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R572 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
R574 CHIP RES.(1608) 1/10W 6.8k Ω ±5% RRXAJR5Z0682 4835 111 37272
R576 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
●
R577 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R578 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R579 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
R580 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
R582 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R583 CARBON RES. 1/4W 10k Ω ±5% RCX4JATZ0103 4835 110 57026
R584 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
●
R586 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
R588 CARBON RES. 1/4W 1.8k Ω ±5% RCX4JATZ0182 4835 110 57033
R590 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R591 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
●
R593 CHIP RES.(1608) 1/10W 270 Ω ±5% RRXAJR5Z0271 4835 111 37424
R594 CARBON RES. 1/6W 220 Ω ±5% or RCX6JATZ0221 4835 111 37175
CARBON RES. 1/4W 220 Ω ±5% RCX4JATZ0221 4835 110 57037
●
R595 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
R596 CARBON RES. 1/6W 8.2k Ω ±2% or RCX6GATZ0822 4835 111 37209
CARBON RES. 1/4W 8.2k Ω ±2% RCX4GATZ0822 4835 110 57264
R597 CARBON RES. 1/6W 1k Ω ±2% or RCX6GATZ0102 4835 111 37162
CARBON RES. 1/4W 1k Ω ±2% RCX4GATZ0102 4835 110 57195
R598 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R599 CARBON RES. 1/6W 3.3k Ω ±5% or RCX6JATZ0332 4835 111 37185
CARBON RES. 1/4W 3.3k Ω ±5% RCX4JATZ0332 4835 110 57046
R600 CARBON RES. 1/6W 100k Ω ±5% or RCX6JATZ0104 4835 110 57068
CARBON RES. 1/4W 100k Ω ±5% RCX4JATZ0104 4835 110 57185
R601 CARBON RES. 1/6W 220k Ω ±5% or RCX6JATZ0224 4835 110 57208
CARBON RES. 1/4W 220k Ω ±5% RCX4JATZ0224 4835 110 57208
R602 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R603 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R604 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R605 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R606 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R607 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R608 CARBON RES. 1/6W 68k Ω ±5% or RCX6JATZ0683 4835 111 37205
CARBON RES. 1/4W 68k Ω ±5% RCX4JATZ0683 4835 110 57168
R609 CARBON RES. 1/4W 10k Ω ±5% RCX4JATZ0103 4835 110 57026
R611 CARBON RES. 1/4W 10k Ω ±5% RCX4JATZ0103 4835 110 57026
R612 CARBON RES. 1/6W 10 Ω ±5% or RCX6JATZ0100 4835 111 37159
CARBON RES. 1/4W 10 Ω ±5% RCX4JATZ0100 4835 110 57002
R613 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R614 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R615 CARBON RES. 1/6W 47k Ω ±5% or RCX6JATZ0473 4835 110 57189
CARBON RES. 1/4W 47k Ω ±5% RCX4JATZ0473 4835 110 57189
R616 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R617 CARBON RES. 1/6W 220 Ω ±5% or RCX6JATZ0221 4835 111 37175
CARBON RES. 1/4W 220 Ω ±5% RCX4JATZ0221 4835 110 57037
R618 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R619 CARBON RES. 1/6W 4.7k Ω ±2% or RCX6GATZ0472 4835 111 37194
CARBON RES. 1/4W 4.7k Ω ±2% RCX4GATZ0472 4835 110 57278
R620 CARBON RES. 1/6W 68k Ω ±5% or RCX6JATZ0683 4835 111 37205
CARBON RES. 1/4W 68k Ω ±5% RCX4JATZ0683 4835 110 57168
R622 CARBON RES. 1/6W 33 Ω ±5% or RCX6JATZ0330 4835 111 17451
CARBON RES. 1/4W 33 Ω ±5% RCX4JATZ0330 4835 110 57044
R623 CARBON RES. 1/6W 47 Ω ±5% or RCX6JATZ0470 4835 111 37192
CARBON RES. 1/4W 47 Ω ±5% RCX4JATZ0470 4835 110 57019
R624 CARBON RES. 1/6W 33 Ω ±5% or RCX6JATZ0330 4835 111 17451
CARBON RES. 1/4W 33 Ω ±5% RCX4JATZ0330 4835 110 57044
R625 CARBON RES. 1/6W 470 Ω ±5% or RCX6JATZ0471 4835 111 37193
CARBON RES. 1/4W 470 Ω ±5% RCX4JATZ0471 4835 110 57167
Ref. No. # Description ID No. Part No.
R626 CARBON RES. 1/6W 470 Ω ±5% or RCX6JATZ0471 4835 111 37193
CARBON RES. 1/4W 470 Ω ±5% RCX4JATZ0471 4835 110 57167
R627 CARBON RES. 1/6W 680 Ω ±5% or RCX6JATZ0681 4835 111 37203
CARBON RES. 1/4W 680 Ω ±5% RCX4JATZ0681 4835 110 57054
R628 CARBON RES. 1/6W 680 Ω ±5% or RCX6JATZ0681 4835 111 37203
CARBON RES. 1/4W 680 Ω ±5% RCX4JATZ0681 4835 110 57054
R629 CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R630 CARBON RES. 1/6W 150 Ω ±5% or RCX6JATZ0151 4835 111 37167
CARBON RES. 1/4W 150 Ω ±5% RCX4JATZ0151 4835 110 57031
R660 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
R662 CARBON RES. 1/4W 8.2k Ω ±5% RCX4JATZ0822 4835 110 57264
R663 CARBON RES. 1/4W 8.2k Ω ±5% RCX4JATZ0822 4835 110 57264
R664 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
R665 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
R666 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
●
R667 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
R668 CARBON RES. 1/4W 22 Ω ±5% RCX4JATZ0220 4835 110 57036
R669 CARBON RES. 1/4W 22 Ω ±5% RCX4JATZ0220 4835 110 57036
R671 CARBON RES. 1/6W 100 Ω ±5% or RCX6JATZ0101 4835 111 37161
CARBON RES. 1/4W 100 Ω ±5% RCX4JATZ0101 4835 110 57003
R672 CARBON RES. 1/6W 1.5k Ω ±5% or RCX6JATZ0152 4835 111 37306
CARBON RES. 1/4W 1.5k Ω ±5% RCX4JATZ0152 4835 110 57186
R673 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
●
R675 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R687 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R688 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R689 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R690 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R691 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R692 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R693 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R695 CHIP RES.(1608) 1/10W 220 Ω ±5% RRXAJR5Z0221 4835 111 37371
R696 CARBON RES. 1/4W 560 Ω ±5% RCX4JATZ0561 4835 110 57052
R697 CARBON RES. 1/4W 560 Ω ±5% RCX4JATZ0561 4835 110 57052
●
R698 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R699 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
R700 CARBON RES. 1/6W 1k Ω ±5% or RCX6JATZ0102 4835 111 37162
CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R701 CARBON RES. 1/6W 1k Ω ±5% or RCX6JATZ0102 4835 111 37162
CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
R702 CARBON RES. 1/6W 1M Ω ±5% or RCX6JATZ0105 4835 110 57272
CARBON RES. 1/4W 1M Ω ±5% RCX4JATZ0105 4835 110 57272
●
R1351 CHIP RES.(1608) 1/10W 1.8k Ω ±5% RRXAJR5Z0182 4835 111 37231
●
R1352 CHIP RES.(1608) 1/10W 2.2k Ω ±5% RRXAJR5Z0222 4835 111 37234
●
R1353 CHIP RES.(1608) 1/10W 2.2k Ω ±5% RRXAJR5Z0222 4835 111 37234
●
R1354 CHIP RES.(1608) 1/10W 220 Ω ±5% RRXAJR5Z0221 4835 111 37371
●
R1355 CHIP RES.(1608) 1/10W 75 Ω ±5% RRXAJR5Z0750 4835 111 17131
●
R1356 CHIP RES.(1608) 1/10W 100k Ω ±5% RRXAJR5Z0104 4835 111 37434
●
R1357 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
SWITCHES
SW201 LEAF SWITCH MXS01830MVP0 SSC0101MCE03 4835 276 17354
SW202 ROTARY MODE SWITCH SSS-53MD SSR0106KB003 4835 276 17357
SW203 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
MISCELLANEOUS
2B16 BUSH, LED(F) 0VM409508 ---- --- -----
2B17 SHIELD ASSEMBLY 0VM413279 ---- --- -----
2B40 HOLDER, F.I.P. 0VM416304 ---- --- -----
F201 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
F202 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
F203 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
F204 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
F205 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
F206 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
FM1001 DC FAN MOTOR 2410-RL-04W-B20-C02 MMEZR12NM004 9965 000 25457
J31 CARBON RES. 1/6W 1k Ω ±5% or RCX6JATZ0102 4835 111 37162
CARBON RES. 1/4W 1k Ω ±5% RCX4JATZ0102 4835 110 57025
Ref. No. # Description ID No. Part No.
