20040914 1-18-10 E9480EL
FUNCTION CBA
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
J373 CERAMIC CAP.(AX) 1000pF/50V ±10%
(B)
CCA1JKT0B102 4835 122 47004
J378 CERAMIC CAP.(AX) 0.1µF/25V ±10% (B) CCA1EKT0B104 4835 122 47682
●
JC1 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC05 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC106 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC107 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC101 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC102 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC103 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC104 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC114 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC116 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC117 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC118 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC119 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
●
JC121 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000 4835 111 37215
JK201 S TYPE JACK(2P) MDC-021V-AA LF JYEL040LY004 9965 000 25469
JK202 RCA JACK MSP-382V-12 PBSN JXRL020LY063 9965 000 15321
JK203 RCA JACK 3P MSP-213-V1-432 PBSN JXRL030LY048 4835 265 97523*
JK204 RCA JACK(BLACK) MSP-281V2-B JXRL010LY062 4835 265 97515
JK205 RCA JACK MSP-382V-12 PBSN JXRL020LY063 9965 000 15321
JK207 RCA JACK 3P MSP-213-V1-432 PBSN JXRL030LY048 4835 265 97523*
JK208 RCA JACK MSP-213V1-652 PBSN or JXRL030LY061 4835 265 97516
RCA JACK MSP-213V1-652-B NI L JXRL030LY116 4835 265 97516
JK210 RCA JACK MSP-213V1-652 PBSN or JXRL030LY061 4835 265 97516
RCA JACK MSP-213V1-652-B NI L JXRL030LY116 4835 265 97516
RM201 INFRARED RECEIVER MODULE MIM-
93M6EKF
USESJRSUNT08 9965 000 25479
TP204 PCB JUMPER D0.6-P5.5 JW5.5T ---- --- -----
TP205 PCB JUMPER D0.6-P10.0 JW10.0T ---- --- -----
TP301 PCB JUMPER D0.6-P20.0 JW20.0T ---- --- -----
TP302 PCB JUMPER D0.6-P10.0 JW10.0T ---- --- -----
TP452 PCB JUMPER D0.6-P21.5 JW21.5T ---- --- -----
TP506 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
TP507 PCB JUMPER D0.6-P25.0 JW25.0T ---- --- -----
TP513 PCB JUMPER D0.6-P7.5 JW7.5T ---- --- -----
TP751 PCB JUMPER D0.6-P10.0 JW10.0T ---- --- -----
TU201 TUNER VH025AG UTUNNTUSP028 9965 000 25480
VR201 CARBON P.O.T. 100k Ω B VRCB104HH014 4835 100 97191
W003 PARALLEL WIRE, 5P AWG26#2651/P2.0/
140
WX1E9480-003 ---- --- -----
W004 FFC CABLE 7P FFC/P1.00/100 WX1E9480-004 ---- --- -----
W005 FFC CABLE 7P FFC/P1.00/220 WX1E9480-005 ---- --- -----
W006 FFC CABLE 8P FFC/P1.00/150 WX1E9480-006 ---- --- -----
W008 FFC CABLE 13P FFC/P1.00/100 WX1E9480-008 ---- --- -----
W010 FFC CABLE 22P FFC/P1.00/120 WX1E9480-010 ---- --- -----
W011 FFC CABLE 22P FFC/P1.00/250 WX1E9480-011 ---- --- -----
W013 WIRE ASSEMBLY 12P UL1007 AWG26/
120
WX1E9480-013 ---- --- -----
W014 WIRE ASSEMBLY 4P UL1007 AWG22/
120
WX1E9480-014 9965 000 25487
W020 WIRE 1P WIRE 1P AWG26 /90 WX1E9480-020 ---- --- -----
X201 CRYSTAL OSCILLATOR 14.31818MHZ or FXD146LDS003 4835 242 77305
CRYSTAL OSCILLATOR 14.31M(20/15/
50/49S)
FXC146LLN004 4835 242 77305
X202 CRYSTAL OSCILLATOR
3.579545MHz(20PPM) or
FXC355LLN003 4835 242 77093
CRYSTAL OSCILLATOR
3.579545MHz(20PPM) or
FXC355LCHE01 4835 242 77093
CRYSTAL OSCILLATOR
3.579545MHz(20PPM)
FXC355LDS001 4835 242 77093
Ref. No. # Description ID No. Part No.
FUNCTION CBA (MCV-B)
Consists of the following:
----------
DIODES
D951 LED(YELLOW) 204YD/E NPQZ00204YDE 4835 130 87169
D952 LED(YELLOW) 204YD/E NPQZ00204YDE 4835 130 87169
RESISTORS
●
R951 CHIP RES.(1608) 1/10W 47k Ω ±5% RRXAJR5Z0473 4835 111 37427
Ref. No. # Description ID No. Part No.
●
R952 CHIP RES.(1608) 1/10W 150 Ω ±5% RRXAJR5Z0151 4835 111 37334
●
R953 CHIP RES.(1608) 1/10W 150 Ω ±5% RRXAJR5Z0151 4835 111 37334
SWITCHES
SW951 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW952 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
Ref. No. # Description ID No. Part No.
SENSOR CBA
Consists of the following:
1VSA10578 9965 000 14801
TRANSISTORS
Q236 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12 4835 130 48222
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F 4835 130 48231
Q238 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12 4835 130 48222
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F 4835 130 48231
Ref. No. # Description ID No. Part No.
PSV CBA
Consists of the following:
1VSA10556 9965 000 25435
POWER SUPPLY CBA (PSV-A)
JUNCTION-A CBA (PSV-B)
JUNCTION-B CBA (PSV-C)
FRONT CBA (PSV-D)
JACK-A CBA (PSV-E)
JACK-B CBA (PSV-G)
--------------
--------------
--------------
--------------
--------------
--------------
Ref. No. # Description ID No. Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
--------------
CAPACITORS
C1001 ELECTROLYTIC CAP. 10µF/50V ±20%
H7
CE1JMASSL100 4835 124 47202
C1002 ELECTROLYTIC CAP. 1000µF/16V ±20%
or
CE1CMZPDL102 4835 124 47005
ELECTROLYTIC CAP. 1000µF/16V ±20% CE1CMZPTL102 4835 124 47005
C1003 ELECTROLYTIC CAP. 10µF/16V ±20%
H7
CE1CMAVSL100 4835 124 47268
C1004 ELECTROLYTIC CAP. 4700µF/6.3V ±20% CE0KMZPTL472 4835 121 47192
C1005 ELECTROLYTIC CAP. 470µF/6.3V ±20%
or
CE0KMASDL471 4835 124 47239
ELECTROLYTIC CAP. 470µF/6.3V ±20% CE0KMASTL471 4835 124 47239
C1006 ELECTROLYTIC CAP. 470µF/6.3V ±20%
or
CE0KMASDL471 4835 124 47239
ELECTROLYTIC CAP. 470µF/6.3V ±20% CE0KMASTL471 4835 124 47239
C1008 ELECTROLYTIC CAP. 22µF/50V ±20% or CE1JMASDL220 4835 124 47051
ELECTROLYTIC CAP. 22µF/50V ±20% CE1JMASTL220 4835 124 47051
C1010 ELECTROLYTIC CAP. 1000µF/25V ±20%
or
CE1EMZPDL102 4835 124 47007
ELECTROLYTIC CAP. 1000µF/25V ±20% CE1EMZPTL102 4835 124 47007
C1011 ELECTROLYTIC CAP. 470µF/10V ±20%
or
CE1AMASDL471 4835 124 47286
ELECTROLYTIC CAP. 470µF/10V ±20% CE1AMASTL471 4835 124 47286
C1012 ELECTROLYTIC CAP. 100µF/10V ±20%
H7
CE1AMASSL101 4835 124 47323
●
C1013 CHIP CERAMIC CAP. 0.01µF/50V ±10%
(B) or
CHD1JKB0B103 4835 122 87255
CHIP CERAMIC CAP.(1608) 0.01µF/50V
±10% (B)
CHD1JK30B103 4835 122 87255
C1014 CERAMIC CAP.(AX) 0.033µF/50V ±10%
(B)
CA1J333TU011 4822 121 42772
C1015 # METALLIZED FILM CAP. 0.068µF/275V
±10% or
CT2E683HJE14 4835 121 47725
# METALLIZED FILM CAP. 0.068µF/275V
±10% or
CT2E683HJE06 4835 121 47725
# METALLIZED FILM CAP. 0.068µF/250V
±10% or
CT2E683DC011 4835 121 47724
# METALLIZED FILM CAP. 0.068µF/250V
±20% or
CT2E683MS037 4835 121 47724
Ref. No. # Description ID No. Part No.
