Philips DVDR600VR/37 - Page 119

20040914 1-18-12 E9480EL
JUNCTION-A CBA
JUNCTION-B CBA
FRONT CBA
R1023 CARBON RES. 1/4W 680k Ω ±5% RCX4JATZ0684 4835 110 57227
R1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M 4835 130 37048
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 4835 130 37235
R1025 CARBON RES. 1/6W 100k Ω ±5% or RCX6JATZ0104 4835 110 57068
CARBON RES. 1/4W 100k Ω ±5% RCX4JATZ0104 4835 110 57185
●
R1026 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJB5Z0103 4835 111 27027
R1027 CARBON RES. 1/6W 100k Ω ±5% or RCX6JATZ0104 4835 110 57068
CARBON RES. 1/4W 100k Ω ±5% RCX4JATZ0104 4835 110 57185
R1028 CARBON RES. 1/6W 470k Ω ±5% or RCX6JATZ0474 4835 110 57225
CARBON RES. 1/4W 470k Ω ±5% RCX4JATZ0474 4835 110 57225
R1029 METAL OXIDE FILM RES. 2W 1.8 Ω ±5%
or
RN021R8DP004 4835 116 67311
METAL OXIDE FILM RES. 2W 1.8 Ω ±5%
or
RN021R8ZU001 4835 116 67311
METAL OXIDE FILM RES. 2W 1.8 Ω ±5% RN021R8KE010 4835 116 67311
R1030 CARBON RES. 1/6W 2.2k Ω ±5% or RCX6JATZ0222 4835 111 37176
CARBON RES. 1/4W 2.2k Ω ±5% RCX4JATZ0222 4835 110 57079
R1031 CARBON RES. 1/6W 2.2k Ω ±5% or RCX6JATZ0222 4835 111 37176
CARBON RES. 1/4W 2.2k Ω ±5% RCX4JATZ0222 4835 110 57079
R1033 CARBON RES. 1/4W 68k Ω ±5% RCX4JATZ0683 4835 110 57168
MISCELLANEOUS
2B18 HEATSINK V2600PZ 0VM409007A ---- --- -----
2L019 SCREW, S-TIGHT M3X8 BIND HEAD+ GBMS3080 ---- --- -----
AC1001 # AC CORD A0A0280-018 or WAC0172LTE07 4835 321 17163
# AC CORD PB8K9F9110A-05A WAC0172LW012 4835 321 17163
F1001 # FUSE SIC 1.25A 250V U/C or PAGK20CW3122 4835 253 97174
# FUSE 1.25A/250V PAGG20CAG122 4835 253 97174
FH1001 FUSE HOLDER MSF-015 or XH01Z00LY001 ---- --- -----
FUSE HOLDER DFH-001 XH01Z00RP001 ---- --- -----
FH1002 FUSE HOLDER MSF-015 or XH01Z00LY001 ---- --- -----
FUSE HOLDER DFH-001 XH01Z00RP001 ---- --- -----
GP1001 # GAP. FNR-G3.10D FAZ000LD6005 4835 252 27025
SA1001 # SURGE ABSORBER 470V+-10PER or NVQZ10D471KB 4835 252 27024
# SURGE ABSORBER CNR-10D471K NVQZR10D471K 4835 252 27024
T1001 # SWITCHING TRANS. 4729-S02 LTT00CPKT157 9965 000 25514
W001 PARALLEL WIRE, 9P AWG26#2651/P2.0/
90
WX1E9480-001 ---- --- -----
W002 PARALLEL WIRE, 9P AWG26#2651/P2.0/
200
WX1E9480-002 ---- --- -----
Ref. No. # Description ID No. Part No.
JUNCTION-A CBA (PSV-B)
Consists of the following:
--------------
CONNECTOR
CN1612 CONNECTOR, 9P TUC-P09X-B1 JCTUS09TG001 ---- --- -----
Ref. No. # Description ID No. Part No.
JUNCTION-B CBA (PSV-C)
Consists of the following:
--------------
CONNECTOR
CN1613 CONNECTOR, 9P TUC-P09X-B1 JCTUS09TG001 ---- --- -----
Ref. No. # Description ID No. Part No.
FRONT CBA (PSV-D)
Consists of the following:
--------------
CAPACITORS
C801 ELECTROLYTIC CAP. 10µF/25V ±20%
H7
CE1EMAVSL100 4822 124 41291
●
C802 CHIP CERAMIC CAP.(1608) 0.047µF/50V
±10% (B) or
CHD1JK30B473 4835 122 87162
CHIP CERAMIC CAP.(1608) 0.047µF/25V
±10% (B)
CHD1EK30B473 4835 122 87185
●
C803 CHIP CERAMIC CAP. 1000pF/50V ±10%
(B) or
CHD1JKB0B102 4835 122 87443
CHIP CERAMIC CAP.(1608) 1000pF/50V
±10% (B)
CHD1JK30B102 4835 122 87153
C804 TF CAP. ECQV1H684JL CT1J684MS042 9965 000 25517
Ref. No. # Description ID No. Part No.
C805 ELECTROLYTIC CAP. 22µF/25V ±20%
H7
CE1EMAVSL220 9965 000 25518
C806 ELECTROLYTIC CAP. 47µF/35V ±20% H7
or
CE1GMASSL470 4835 124 97066
ELECTROLYTIC CAP. 47µF/50V ±20% H7 CE1JMASSL470 4835 124 47507
●
C807 CHIP CERAMIC CAP.(1608) 0.1µF/25V
±10% (B) or
CHD1EK30B104 4835 122 87213
CHIP CERAMIC CAP.(1608) 0.1µF/16V
±10% (B)
CHD1CK30B104 4835 122 87634
●
C809 CHIP CERAMIC CAP.(1608) 0.22µF/16V
±10% (B) or
CHD1CK30B224 4835 122 87135
CHIP CERAMIC CAP.(1608) 0.22µF/25V
±10% (B)
CHD1EK30B224 4835 122 87152
●
C810 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C811 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C812 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C813 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C814 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C815 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C816 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C817 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C818 CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CH) or
CHD1JJ3CH101 4835 122 87193
CHIP CERAMIC CAP.(1608) 100pF/50V
±5%(CG)
CHD1JJ3CG101 4835 122 87193
●
C819 CHIP CERAMIC CAP.(1608) 0.01µF/50V
±10% (B)
CHD1JK30B103 4835 122 87255
●
C820 CHIP CERAMIC CAP.(1608) 0.01µF/50V
±10% (B)
CHD1JK30B103 4835 122 87255
●
C821 CHIP CERAMIC CAP.(1608) 0.047µF/50V
±10% (B) or
CHD1JK30B473 4835 122 87162
CHIP CERAMIC CAP.(1608) 0.047µF/25V
±10% (B)
CHD1EK30B473 4835 122 87185
C822 ELECTROLYTIC CAP. 22µF/16V ±20%
H7
CE1CMAVSL220 4835 124 47175
CONNECTORS
CN801 FFC/FPC CONNECTOR, 13P 00-6232-
013-006-800 or
JC62G13TM010 ---- --- -----
FMN CONNECTOR, TOP 13P 13FMN-
BTK
JCFNG13JG001 ---- --- -----
DIODES
D801 ZENER DIODE DZ-6.8BSCT265 or NDTC0DZ6R8BS 4835 130 38027
ZENER DIODE MTZJT-776.8C QDTC0MTZJ6R8 4835 130 37881
D802 SWITCHING DIODE 1N4148M or NDTZ01N4148M 4835 130 37048
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 4835 130 37235
D803 SWITCHING DIODE 1N4148M or NDTZ01N4148M 4835 130 37048
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 4835 130 37235
IC
●
IC801 IC, FRONT PANEL CONTROL
TMP87CH74AF-3RU1(Z)
QSZAA0RTS015 4835 209 47642
COILS
L801 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L802 PCB JUMPER D0.6-P5.0 JW5.0T ---- --- -----
L803 INDUCTOR 180µH-K-26T LLAXKATTU181 4835 157 57372
TRANSISTORS
Q801 SWITCHING BC337-25-AT NQS8000BC337 9965 000 25475
Q802 SWITCHING BC327-25-AT NQS8000BC327 3198 020 43430
Ref. No. # Description ID No. Part No.
