20040914 1-18-13 E9480EL
JACK-A CBA
JACK-B CBA
Q803 SWITCHING BC547-S-BB NQSB000BC547 9965 000 25523
Q805 INVERTER BC547-S-BB NQSB000BC547 9965 000 25523
Q806 DRIVE BC547-S-BB NQSB000BC547 9965 000 25523
Q807 DRIVE BC547-S-BB NQSB000BC547 9965 000 25523
RESISTORS
●
R801 CHIP RES.(1608) 1/10W 100 Ω ±5% RRXAJR5Z0101 4835 111 37432
●
R802 CHIP RES.(1608) 1/10W 100 Ω ±5% RRXAJR5Z0101 4835 111 37432
R803 CARBON RES. 1/6W 10k Ω ±5% RCX6JATZ0103 4835 111 37163
R804 CARBON RES. 1/6W 470 Ω ±5% RCX6JATZ0471 4835 111 37193
R805 CARBON RES. 1/6W 470 Ω ±5% RCX6JATZ0471 4835 111 37193
●
R806 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R807 CHIP RES.(1608) 1/10W 470 Ω ±5% RRXAJR5Z0471 4835 111 37259
●
R808 CHIP RES.(1608) 1/10W 330 Ω ±5% RRXAJR5Z0331 4835 111 37443
●
R809 CHIP RES.(1608) 1/10W 330 Ω ±5% RRXAJR5Z0331 4835 111 37443
●
R810 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R811 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R812 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R813 CHIP RES.(1608) 1/10W 100 Ω ±5% RRXAJR5Z0101 4835 111 37432
●
R814 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R815 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R816 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R817 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R818 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R819 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R820 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R822 CHIP RES.(1608) 1/10W 100k Ω ±5% RRXAJR5Z0104 4835 111 37434
●
R823 CHIP RES.(1608) 1/10W 100k Ω ±5% RRXAJR5Z0104 4835 111 37434
●
R825 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R826 CHIP RES.(1608) 1/10W 22k Ω ±5% RRXAJR5Z0223 4835 111 37441
●
R827 CHIP RES.(1608) 1/10W 10k Ω ±5% RRXAJR5Z0103 4835 111 37216
●
R828 CHIP RES.(1608) 1/10W 220 Ω ±5% RRXAJR5Z0221 4835 111 37371
●
R829 CHIP RES.(1608) 1/10W 47k Ω ±5% RRXAJR5Z0473 4835 111 37427
R830 THERMAL SENSOR LT1/
6CT26A103J1000
RTX6103KA008 4835 276 17358
●
R831 CHIP RES.(1608) 1/10W 2.2k Ω ±5% RRXAJR5Z0222 4835 111 37234
●
R832 CHIP RES.(1608) 1/10W 2.2k Ω ±5% RRXAJR5Z0222 4835 111 37234
●
R833 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R835 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R836 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
SWITCHES
SW801 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW802 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW803 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
2B41 HOLDER, F.I.P. 2 H5341UD 0VM407372 ---- --- -----
FIP801 V.F.D BJ944GN TVFD1C0FT046 9965 000 25520
X801 CERAMIC RESONETOR
CSTLS8M00G56-B0
FY0805PMR002 9965 000 25524
Ref. No. # Description ID No. Part No.
JACK-A CBA (PSV-E)
Consists of the following:
--------------
CAPACITORS
●
C751 CHIP CERAMIC CAP. 330pF/50V ±10%
(B)
CHD1JK30B331 4835 122 87032
●
C752 CHIP CERAMIC CAP. 330pF/50V ±10%
(B)
CHD1JK30B331 4835 122 87032
●
C753 CHIP CERAMIC CAP.(1608) 47pF/50V
±5% (CH) or
CHD1JJ3CH470 4835 122 87148
CHIP CERAMIC CAP. 47pF/50V ±5%
(CG)
CHD1JJ3CG470 4835 122 87034
CONNECOTRS
CN751 FFC/FPC CONNECTOR, 8P 00-6232-
008-006-800 or
JC62G08TM010 ---- --- -----
Ref. No. # Description ID No. Part No.
FMN CONNECTOR, TOP 8P 08FMN-
BTRK
JCFNG08JG002 ---- --- -----
DIODE
D751 LED(RED) 204HD/E NPQZ00204HDE 4835 130 87166
TRANSISTORS
Q751 ZENER DIODE UMZ6.8N T106 QD1Z0UMZ6R8N 9965 000 25531
Q752 ZENER DIODE UMZ6.8N T106 QD1Z0UMZ6R8N 9965 000 25531
Q753 ZENER DIODE UMZ6.8N T106 QD1Z0UMZ6R8N 9965 000 25531
RESISTORS
●
R751 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R752 CHIP RES.(1608) 1/10W 1M Ω ±5% RRXAJR5Z0105 4835 111 37217
●
R753 CHIP RES.(1608) 1/10W 1.8k Ω ±5% RRXAJR5Z0182 4835 111 37231
●
R754 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R755 CHIP RES.(1608) 1/10W 150 Ω ±5% RRXAJR5Z0151 4835 111 37334
●
R756 CHIP RES.(1608) 1/10W 75 Ω ±5% RRXAJR5Z0750 4835 111 17131
●
R757 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R758 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R759 CHIP RES.(1608) 1/10W 68 Ω ±5% RRXAJR5Z0680 4835 111 37408
SWITCHES
SW751 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW752 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW753 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
JK751 RCA PIN JACK RJ-1169*02-1300B JYRJ010JD001 9965 000 25528
JK752 RCA PIN JACK RJ-1169*03-1300B JYRJ010JD002 9965 000 25529
JK753 RCA PIN JACK RJ-1169*04-1300A JXRJ010JD003 9965 000 25530
Ref. No. # Description ID No. Part No.
JACK-B CBA (PSV-G)
Consists of the following:
--------------
CAPACITORS
●
C901 CHIP CERAMIC CAP.(1608) 0.1µF/25V
±10% (B) or
CHD1EK30B104 4835 122 87213
CHIP CERAMIC CAP.(1608) 0.1µF/16V
±10% (B)
CHD1CK30B104 4835 122 87634
CONNECTOR
CN901 FFC/FPC CONNECTOR 7P 00 6232 007
104 800
JC62G07UG022 9965 000 25532
TRANSISTORS
Q901 ZENER DIODE UMZ6.8N T106 QD1Z0UMZ6R8N 9965 000 25531
Q902 ZENER DIODE UMZ6.8N T106 QD1Z0UMZ6R8N 9965 000 25531
RESISTORS
●
R901 CHIP RES.(1608) 1/10W 1.8k Ω ±5% RRXAJR5Z0182 4835 111 37231
●
R902 CHIP RES.(1608) 1/10W 1.2k Ω ±5% RRXAJR5Z0122 4835 111 37222
●
R903 CHIP RES.(1608) 1/10W 1k Ω ±5% RRXAJR5Z0102 4835 111 17068
●
R904 CHIP RES.(1608) 1/10W 1.5k Ω ±5% RRXAJR5Z0152 4835 111 37437
●
R905 CHIP RES.(1608) 1/10W 75 Ω ±5% RRXAJR5Z0750 4835 111 17131
●
R906 CHIP RES.(1608) 1/10W 75 Ω ±5% RRXAJR5Z0750 4835 111 17131
●
R907 CHIP RES.(1608) 1/10W 2.2k Ω ±5% RRXAJR5Z0222 4835 111 37234
SWITCHES
SW901 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW902 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW903 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
TACT SWITCH SKQSAF001A or SST0101AL041 4835 276 17282
TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
SW904 TACT SWITCH KSM0614B or SST0101HH013 4835 276 17282
SW904 TACT SWITCH SKQSAF001A SST0101AL041 4835 276 17282
SW904 TACT SWITCH TC-1104(H=9.5) SST0101DNG01 4835 276 17356
Ref. No. # Description ID No. Part No.
