2-4-1 U29NDA_PC
DISASSEMBLY/ASSEMBLY PROCEDURES
OF DECK MECHANISM
Before following the procedures described below, be sure to remove the deck assembly from the cabinet. (Refer to
CABINET DISASSEMBLY INSTRUCTIONS of Main Section.)
All the following procedures, including those for adjustment and replacement of parts, should be done in Eject
mode; see the positions of [41] and [42] in Fig. DM1 on page 2-4-3. When reassembling, follow the steps in reverse
order.
Comparison Chart of Models and Marks
Model Deck Part No. Mark Model Deck Part No. Mark
MC132EMG/17 N2226FT A MDV540VR/17 N2260FL G
MVR440MG/17 N2240FL B 19MDTR20/17 N2266FT H
MVR450MG/17 N2240FL C 20MC4304/17 N2266FT I
MVR650MG/17 N2260FL D 27MC4304/17 N2266FT J
DVP620VR/17 N2260FL E 27MDTR20/17 N2266FT K
DVP620VR/07 N2260FL F
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
[1] [1] Guide Holder A T DM3 2(S-1)
[2] [1]
Cassette Holder
Assembly
T DM4 (S-10) --- [ A,H,I,J,K ]
[3] [2] Slider (SP) T DM5 (S-1A), *(L-1)
[4] [2] Slider (TU) T DM5 *(L-2)
[5] [4] Lock Lever T DM5 *(L-3), *(P-1)
[6] [2] Cassette Plate T DM5
[7] [7] Cylinder Assembly T DM1, DM6 Desolder, 3(S-2)
[8] [8] Loading Motor Assembly T DM1, DM7
Desolder, LDG Belt,
2(S-3)
[9] [9] ACE Head Assembly T DM1, DM7 (S-4)
[10] [2]
Tape Guide Arm
Assembly
TDM1, DM8-1 *(P-2)
[11] [10] C Door Opener T DM1, DM8-1 (S-4A), *(L-4)
[12] [11] Pinch Arm (B) T
DM1, DM8-1,
DM8-2
*(P-3)
[13] [12] Pinch Arm (A) Assembly T
DM1, DM8-1,
DM8-2
[14] [14] FE Head T DM1, DM9 (S-5)
[15] [15] Prism T DM1, DM9 (S-6)
[16] [2],[15] Sensor Gear T DM1, DM9
[17] [2] Slider Shaft T DM10 *(L-5)
[18] [17] C Drive Lever (SP) T DM10
[19] [17] C Drive Lever (TU) T DM10 (S-7), *(P-4)
[20]
[7],[8],
[10]
Capstan Motor B DM2, DM11 3(S-8), Cap Belt
[21] [21] Clutch Assembly B DM2, DM12 (C-1)
