(1): Follow steps in sequence. When reassembling, follow the steps in reverse order.
These numbers are also used as identification (location) No. of parts in the figures.
(2): Indicates the part to start disassembling with in order to disassemble the part in column (1).
(3): Name of the part
(4): Location of the part: T=Top B=Bottom R=Right L=Left
(5): Figure Number
(6): Identification of parts to be removed, unhooked, unlocked, released, unplugged, unclamped, or desoldered.
P=Spring, W=Washer, C=Cut Washer, S=Screw, *=Unhook, Unlock, Release, Unplug, or Desolder
e.g., 2(L-2) = two Locking Tabs (L-2).
(7): Adjustment Information for Installation
(+):Refer to Deck Exploded Views for lubrication.
[22] [22]
Cam Holder(F) --- [ A ]
Cam Holder Assembly ---
[ B,C,D,E,F,G,H,I,J,K ]
B DM2, DM12 *(L-6)
[23] [23] Cam Gear (B) B DM2, DM12 (C-2), *(P-5)
[24] [24] Mode Gear B DM2, DM13-1 (C-3)
[25]
[21],[23],
[24]
Mode Lever B
DM2, DM13-1,
DM13-2
(C-4), *(L-8)
[26] [22] Worm Holder B DM2, DM13-1 (S-9), *(L-9), *(L-10)
[27] [26] Pulley Assembly B DM2, DM13-1
[28] [25],[26] Cam Gear (A) B
DM2, DM13-1,
DM13-2
[29] [25] Idler Gear B DM1, DM14
[30] [29] Idler Arm B DM1, DM14 *(L-11)
[31] [25] BT Arm B DM2, DM14 *(P-6)
[32] [25]
Loading Arm (SP)
Assembly
BDM2, DM14
(+)Refer to Alignment
Sec.Page 2-5-1
[33]
[32]
Loading Arm (TU)
Assembly
BDM2, DM14
(+)Refer to Alignment
Sec.Page 2-5-1
[34] [2],[25] M Brake (TU) Assembly T DM1, DM15 *(P-7), Brake Belt
[35] [2],[25] M Brake (SP) Assembly T DM1, DM15 *(P-8)
[36] [35] Tension Lever Assembly T DM1, DM15
[37] [36] T Lever Holder T DM15 *(L-12)
[38] [34] Reel (TU)(D2) T DM1, DM15
[39] [38] M Gear T DM1, DM15
[40] [36] Reel (SP)(D2) T DM1, DM15
[41] [32],[36]
Moving Guide S
Preparation
TDM1, DM16
[42] [33]
Moving Guide T
Preparation
TDM1, DM16
[43] [19] TG Post Assembly T DM1, DM16 *(L-13)
[44] [28] Rack Assembly R DM17
(+)Refer to Alignment
Sec.Page 2-5-1
[45] [44] F Door Opener R DM17 *(P-9) --- [ A,H,I,J,K ]
[46] [46] Cleaner Assembly T DM1, DM6
[47] [46] CL Post T DM6 *(L-14)
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
↓
(6)
↓
(7)
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
