1-4-2 E9480FIS
< DVD Section >
Note: If an error occurs, a message with the error number appears on the screen.
Description Error No. Error Description
Sends the device id and the module ids and revisions
of the Domino IC to the stdout port.
010000 Getting the information succeeded.
Generates a test-image of a selected video standard
on selected video output on the digital board. When no
input is given, the default values will be used. Use
nucleus DS_ANAB_VideoRouting to route the video
signal on the analogue board output.
010100 Generating the test image succeeded.
010101 Failed to set up DENC.
010102 Invalid user input.
010103 Test image not supported.
Switches the test-image off. 010200 Stopping the test image generation succeeded.
Generate an audio sine signal on the audio output of
the digital board.
010300 The sine signal was successfully generated.
010301 Generating the sine test audio failed.
Stop generating the audio sine signal.
010400 Switching off the audio sine signal succeeded.
010401 Failed to stop sine test audio.
Generate an audio sine signal on the audio output of
the digital board for 4 seconds.
010500 The sine signal burst was successfully generated.
010501 Generating the sine burst failed.
010502 Failed to stop the sine burst.
Mute the audio outputs of the digital board. 010600 Muting the audio succeeded.
De-mute the audio outputs of the digital board. 010700 De-muting the audio succeeded.
Check the connection to the DV-LED on the digital
board by switching it on.
010800 Switching the DV-LED on succeeded.
Switch off the DV-LED on the digital board. 010900 Switching the DV-LED off succeeded
Peek a value on a specified address.
011200 Peeking on the specified address succeeded.
011201 No address input.
011202 Invalid address.
Poke a value on a specified address.
011300 Poking the specified address succeeded.
011301 No address input.
011302 Invalid address/data.
Check the communication between the IIC controller of
the Chrysalis and the EEPROM.
030000 Something is properly read so the communication is OK.
030004 The communication with the NVRAM failed.
030005 The IIC bus initialisation failed.
Check whether the EEPROM can be written to and
read from.
030100 The write-read test succeeded.
030101 The IIC bus initialisation failed.
030102 The communication with the NVRAM failed.
030103 The read back value is different from the written value.
Make the EEPROM empty, containing all zeroes.
030200 The clearing of the NVRAM succeeded.
030201 There was an IIC error.
030202 Clearing the NVRAM failed.
Modifies one or more locations in NVRAM and updates
the checksum of the section modified.
030300 Modifying the NVRAM contents succeeded.
030301 Unable to initialise NVM.
030302 Modifying the NVRAM contents failed.
030303 Length out of range.
030304 Unable to decode length.
030305 Offset out of range.
030306 unable to decode offset.
030307 Unknown location specified.
030308 No location is specified.
030309 Number of values incorrect.
030310 Error creating checksum.
030311 Invalid data.
X X Y Y Z Z
Error code
Nucleus nmber
Nucleus group nmber
