Alignments
EN 78 L04E AB8.
Table 8-3 Default geometry values
8.3.5 Audio
No alignments are needed for the audio sub menu. Use the
given default values.
QSS (Quasi Split Sound)
• For NICAM/2CS sound system (EU/AP, except for
APNTSC), set to “On”.
• For AV-Stereo sound system (sets without NICAM), set to
“On”.
• For all other sets (NAFTA/LATAM/AP-NTSC), set to “Off”.
FMI (Freq. Modulation Intercarrier)
• For NICAM/2CS sound system (EU/AP, except for
APNTSC), set to “On”.
• For AV-Stereo sound system (sets without NICAM), set to
“Off”.
• For dBx/non-dBx sound systems, set to “On”.
NICAM Alignment
• For sets with NICAM/2CS (EU/AP, except for AP-NTSC)
sound system, set to “79”.
• For all other sets (NAFTA/LATAM/AP-NTSC), set to “63” (=
don’t care).
Alignment
Default
values
(hex)
Default
values
(dec)
HP (Horizontal parallelogram) 1F 31
HB (Horizontal Bow) 1F 31
HS (Horizontal shift) 1A 26
EWW (EW width) 25 37
EWP (EW parabola width) 0A 10
EWT (EW trapezium) 1A 26
UCP (EW upper corner parabola) 1E 30
LCP (EW lower corner parabola) 28 40
VSH (Vertical Shift) 1A 26
VS (Vertical slope) 25 37
VAM (Vertical amplitude) 1E 30
VSC (Vertical S-Correction) 19 25
