Philips LC4.1E A - Page 50

Alignments
EN 50 LC4.1E AB8.
Table 8-3 Hercules Default NVM Settings (Option Bit Settings via Nvm Editor in Sam Mode)
Byte Nr Bit Feature/Mode Description
23PF5320/01 23PF5320/58 20PF4110/01 20PF4110/58 20PF5320/01 20PF5320/58 20PF5120/01 20PF5120/58 17PF4310/01 17PF4310/58 15PF5120/01 15PF5120/58 15PF4110/01 15PF4110/58
Byte 0
174(dec)
0 QSS (LSB) Mode of quasi split sound amplifier 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 FMI Connection of output of QSS amplifier 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 HCO EHT tracking mode 0 0 0 0 0 0 0 0 0 0 0 0 0 0
3 HP2 Synchronization of OSD/Text display 1 1 1 1 1 1 1 1 1 1 1 1 1 1
4 FSL Forced slicing level for vertical sync 1 1 1 1 1 1 1 1 1 1 1 1 1 1
5 TFR DC transfer ratio of luminance signal 1 1 1 1 1 1 1 1 1 1 1 1 1 1
6 OSVE Black current measuring in overscan 0 0 0 0 0 0 0 0 0 0 0 0 0 0
7 MVK (MSB) (For Future Usage, as defined by soft-
ware)
00000 0000 0 0 000
Total Dec Values 59 59 59 59 59 59 59 59 59 59 59 59 59 59
Total Hex Values 3B 3B 3B 3B 3B 3B 3B 3B 3B 3B 3B 3B 3B 3B
Byte 1
175(dec)
0 PSE 00000 0000 0 0 000
1 OPC 00000 0000 0 0 000
2PRIS 00000000000000
3 CONTINUOUS FACTORY Continuous factory mode 1 1 1 1 1 1 1 1 1 1 1 1 1 1
4 WHITE PATTERN ON Last color pattern status in factory
mode
00000 0000 0 0 000
5 SDM MODE Service default mode on/off 0 0 0 0 0 0 0 0 0 0 0 0 0 0
6 SAM MODE Service Align mode on/off 0 0 0 0 0 0 0 0 0 0 0 0 0 0
7SVMA Scavm On / Off 00000000000000
Total Dec Values 88888 8888 8 8 888
Total Hex Values 08 08 08 08 08 08 08 08 08 08 08 08 08 08
Byte 2
176(dec)
0 MUTE STATUS Mute status 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 TUNER AUTO MODE Auto mode 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 CABLE MODE Cable/Antenna mode 0 0 0 0 0 0 0 0 0 0 0 0 0 0
3 LAST POWER MODE Last power status of the set 1 1 1 1 1 1 1 1 1 1 1 1 1 1
4 CHILD LOCK MODE Child lock enabled 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5 SURF MODE Surf mode on/off 0 0 0 0 0 0 0 0 0 0 0 0 0 0
6 FACTORY MODE Factory mode on 1 1 1 1 1 1 1 1 1 1 1 1 1 1
7 PSNS For PAL color enhancement in ES4 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Total Dec Values 20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
20
2
Total Hex Values C
A
C
A
C
A
C
A
CA C
A
C
A
C
A
CA CA CA C
A
C
A
C
A
Byte 3
177(dec)
0 RADIO/TV MODE Radio mode or TV mode 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 WAKE-UP MODE 0 0 0 0 0 0 0 0 0 0 0 0 0 0
2 HOTEL MODE TV in Hotel mode 00000 0000 0 0 000
3 HOTEL KBD LOCK Keyboard locked 0 0 0 0 0 0 0 0 0 0 0 0 0 0
4 HBL 00000 0000 0 0 000
5 BLS Blue stretch mode 1 1 1 1 1 1 1 1 1 1 1 1 1 1
6SL 00000000000000
7 CFA0 Comb filter On/Off 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Total Dec Values 32 32 32 32 32 32 32 32 32 32 32 32 32 32
Total Hex Values 20 20 20 20 20 20 20 20 20 20 20 20 20 20
