ELECTRICAL PARTS LIST - P-SCAN BOARD
5-6
ELECTRICAL PARTS LIST - P-SCAN BOARD
MISCELLANEOUS
1000 2422 025 17716 Flex Socket 24P
1005 4822 265 11535 Flex Socket 8P
CAPACITORS
2100 4822 124 81286 47uF 20% 16V
2101 2238 586 59812 100nF +80/-20% 50V
2102 4822 124 81286 47uF 20% 16V
2103 4822 124 81286 47uF 20% 16V
2104 3198 017 41050 1uF 10V
2105 2238 586 59812 100nF +80/-20% 50V
2106 2238 586 59812 100nF +80/-20% 50V
2107 4822 124 81286 47uF 20% 16V
2108 4822 124 11947 10uF 20% 16V
2109 2238 586 59812 100nF +80/-20% 50V
2110 2238 586 59812 100nF +80/-20% 50V
2111 2238 586 59812 100nF +80/-20% 50V
2112 2238 586 59812 100nF +80/-20% 50V
2113 2238 586 59812 100nF +80/-20% 50V
2114 2238 586 59812 100nF +80/-20% 50V
2115 2238 586 59812 100nF +80/-20% 50V
2116 2238 586 59812 100nF +80/-20% 50V
2117 2238 586 59812 100nF +80/-20% 50V
2118 2238 586 59812 100nF +80/-20% 50V
2119 2238 586 59812 100nF +80/-20% 50V
2120 2238 586 59812 100nF +80/-20% 50V
2121 2238 586 59812 100nF +80/-20% 50V
2122 2238 586 59812 100nF +80/-20% 50V
2123 2238 586 59812 100nF +80/-20% 50V
2124 2238 586 59812 100nF +80/-20% 50V
2125 2238 586 59812 100nF +80/-20% 50V
2126 2238 586 59812 100nF +80/-20% 50V
2127 2238 586 59812 100nF +80/-20% 50V
2128 2238 586 59812 100nF +80/-20% 50V
2129 2238 586 59812 100nF +80/-20% 50V
2130 4822 126 13879 220nF +80/-20% 16V
2131 4822 126 13879 220nF +80/-20% 16V
2132 4822 126 13879 220nF +80/-20% 16V
2133 4822 126 13879 220nF +80/-20% 16V
2134 2238 586 59812 100nF +80/-20% 50V
2135 2238 586 59812 100nF +80/-20% 50V
2136 2238 586 59812 100nF +80/-20% 50V
2137 2238 586 59812 100nF +80/-20% 50V
2138 2238 586 59812 100nF +80/-20% 50V
2139 2238 586 59812 100nF +80/-20% 50V
2140 4822 126 13879 220nF +80/-20% 16V
2141 4822 126 13879 220nF +80/-20% 16V
2142 4822 126 13879 220nF +80/-20% 16V
2143 4822 126 13879 220nF +80/-20% 16V
2144 4822 126 13879 220nF +80/-20% 16V
2145 4822 126 13879 220nF +80/-20% 16V
2146 4822 126 13879 220nF +80/-20% 16V
2147 4822 126 13879 220nF +80/-20% 16V
2148 2238 586 59812 100nF +80/-20% 50V
2149 2238 586 59812 100nF +80/-20% 50V
2151 2238 586 59812 100nF +80/-20% 50V
2152 2238 586 59812 100nF +80/-20% 50V
2170 4822 124 12032 4,7uF 20% 50V
2202 2238 586 59812 100nF +80/-20% 50V
2203 4822 124 12245 220uF 20% 10V
2204 4822 124 81286 47uF 20% 16V
2209 2238 586 59812 100nF +80/-20% 50V
2216 2238 586 59812 100nF +80/-20% 50V
2217 2238 586 59812 100nF +80/-20% 50V
2218 2238 586 59812 100nF +80/-20% 50V
2320 4822 124 81286 47uF 20% 16V
2321 4822 124 81286 47uF 20% 16V
2322 4822 124 81286 47uF 20% 16V
2323 4822 124 81286 47uF 20% 16V
2400 4822 122 33753 150pF 5% 50V
2401 2020 552 94427 100pF 5% 50V
2402 2020 552 94427 100pF 5% 50V
2403 2238 586 59812 100nF +80/-20% 50V
2410 4822 122 33753 150pF 5% 50V
2411 2020 552 94427 100pF 5% 50V
2412 2020 552 94427 100pF 5% 50V
2413 2238 586 59812 100nF +80/-20% 50V
2420 4822 122 33753 150pF 5% 50V
2421 2020 552 94427 100pF 5% 50V
2422 2020 552 94427 100pF 5% 50V
2423 2238 586 59812 100nF +80/-20% 50V
RESISTORS
3100 4822 051 30109 10R 5% 0,062W
3101 4822 051 30151 150R 5% 0,062W
3102 2322 702 60279 27R 5% 0,062W
3103 4822 117 12139 22R 5% 0,062W
3104 4822 117 12139 22R 5% 0,062W
3107 4822 051 30101 100R 5% 0,062W
3108 4822 051 30101 100R 5% 0,062W
3109 4822 117 12139 22R 5% 0,062W
3110 4822 117 12139 22R 5% 0,062W
3111 4822 117 12139 22R 5% 0,062W
3112 4822 117 12139 22R 5% 0,062W
3113 4822 117 12139 22R 5% 0,062W
3114 4822 117 12139 22R 5% 0,062W
3115 4822 117 12139 22R 5% 0,062W
3116 4822 117 12139 22R 5% 0,062W
3117 4822 117 12139 22R 5% 0,062W
3118 4822 117 12139 22R 5% 0,062W
3119 4822 117 12139 22R 5% 0,062W
3120 4822 117 12139 22R 5% 0,062W
3121 4822 117 12139 22R 5% 0,062W
3122 4822 117 12139 22R 5% 0,062W
3123 4822 117 12139 22R 5% 0,062W
3124 4822 117 12139 22R 5% 0,062W
3125 4822 117 12139 22R 5% 0,062W
3126 4822 117 12139 22R 5% 0,062W
3127 4822 117 12139 22R 5% 0,062W
3128 4822 117 12139 22R 5% 0,062W
3129 4822 117 12139 22R 5% 0,062W
3130 4822 117 12139 22R 5% 0,062W
3131 4822 117 12139 22R 5% 0,062W
3132 4822 117 12139 22R 5% 0,062W
3133 4822 117 12139 22R 5% 0,062W
3134 4822 117 12139 22R 5% 0,062W
3135 4822 117 12139 22R 5% 0,062W
3136 4822 117 12139 22R 5% 0,062W
3137 4822 117 12139 22R 5% 0,062W
3138 4822 117 12139 22R 5% 0,062W
3139 4822 117 12139 22R 5% 0,062W
3140 4822 117 12139 22R 5% 0,062W
3141 4822 117 12139 22R 5% 0,062W
3142 4822 117 12139 22R 5% 0,062W
3143 4822 117 12139 22R 5% 0,062W
3144 4822 117 12139 22R 5% 0,062W
3145 4822 117 12139 22R 5% 0,062W
3146 4822 117 12139 22R 5% 0,062W
3147 4822 117 12139 22R 5% 0,062W
3148 4822 117 12139 22R 5% 0,062W
3149 4822 117 12139 22R 5% 0,062W
3150 4822 051 30472 4k7 5% 0,062W
3158 4822 117 12139 22R 5% 0,062W
3159 4822 117 12139 22R 5% 0,062W
3160 4822 117 12139 22R 5% 0,062W
3161 4822 117 12139 22R 5% 0,062W
3162 4822 117 12139 22R 5% 0,062W
3163 4822 117 12139 22R 5% 0,062W
3170 4822 051 30472 4k7 5% 0,062W
3401 4822 051 30151 150R 5% 0,062W
3403 4822 051 30151 150R 5% 0,062W
3406 4822 051 30759 75R 5% 0,062W
3411 4822 051 30151 150R 5% 0,062W
3413 4822 051 30151 150R 5% 0,062W
3416 4822 051 30759 75R 5% 0,062W
3421 4822 051 30151 150R 5% 0,062W
3423 4822 051 30151 150R 5% 0,062W
3426 4822 051 30759 75R 5% 0,062W
4100 4822 051 30008 0R Jumper 0603
4101 4822 051 30008 0R Jumper 0603
4103 4822 051 30008 0R Jumper 0603
4105 4822 051 30008 0R Jumper 0603
4110 4822 051 20008 0R Jumper 0805
4201 4822 051 30008 0R Jumper 0603
4203 4822 051 30008 0R Jumper 0603
4405 4822 051 30008 0R Jumper 0603
4415 4822 051 30008 0R Jumper 0603
4425 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5101 4822 157 71593 Coil 10uH 10%
5102 4822 157 71593 Coil 10uH 10%
5201 4822 157 71593 Coil 10uH 10%
5302 4822 157 71593 Coil 10uH 10%
5309 4822 157 71593 Coil 10uH 10%
5310 4822 157 71593 Coil 10uH 10%
5311 4822 157 71593 Coil 10uH 10%
5312 4822 157 71593 Coil 10uH 10%
5400 4822 157 10977 Coil 4,7uH 10%
5401 3198 018 31580 Coil 1,5uH 10%
5410 4822 157 10977 Coil 4,7uH 10%
5411 3198 018 31580 Coil 1,5uH 10%
5420 4822 157 10977 Coil 4,7uH 10%
5421 3198 018 31580 Coil 1,5uH 10%
TRANSISTORS & INTEGRATED CIRCUITS
7100 9322 189 93671 FLI2301
7101 9322 166 71668 MT48LC2M32B2TG-6
7103 9322 167 69668 LD1117ADT18
7200 9352 092 60118 74LVT74DB
7203 9352 092 90118 74LVT86DB
7400 9322 167 49685 AD8061ART
7410 9322 167 49685 AD8061ART
7420 9322 167 49685 AD8061ART
Note: Only the parts mentioned in this list are normal service
spare parts.
