Electrical Partslist
ECO6
SYSTEMS
-
CENELEC
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1101 2422 015 19376 SOCKET CLICKFIT 2P USA only
1102 4822 267 10283 SOCKET COAX, IEC 75Ω not USA
1103 4822 265 31184 JST CONNECTOR, 2 POLE
1110 2422 542 90071 FM FRONTEND
1120 4822 265 11515 FFC SOCKET, 8P
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2102 © 4822 126 13838 100nF 10% 50V not USA
2105 © 4822 126 13838 100nF 10% 50V USA only
2106 2020 800 00204 TRIMCAP. 4,2 - 20pF, N750 LW only
2106 2020 800 00191 TRIMCAP. 3 - 11pF, N450 FM/AM only
2107 4822 121 51319 1µF 20% 50V
2108 © 5322 122 32531 100pF 5% 50V LW only
2109 © 5322 122 32448 10pF 5% 50V LW only
2120 © 4822 126 13689 18pF 1% 63V FM/AM only
2120 © 5322 122 32658 22pF 5% 50V LW only
2122 © 4822 122 33891 3,3nF 10% 63V LW only
2123 © 2020 552 93494 390pF 1% 50V LW only
2124 © 4822 122 33177 10nF 20% 50V FM/AM only
2125 © 2020 552 96199 560pF 1% 50V
2127 © 4822 126 14076 220nF 20% 25V
2128 4822 124 40248 10µF 20% 63V
2129 4822 124 41584 100µF 20% 10V
2130 © 5322 122 32654 22nF 10% 63V
2131 © 4822 126 13482 470nF 20% 16V
2132 © 4822 126 13482 470nF 20% 16V
2133 4822 124 21913 1µF 20% 63V
2134 © 3198 017 31530 15nF 10% 50V not USA
2134 © 5322 122 32654 22nF 10% 63V USA only
2135 © 3198 017 31530 15nF 10% 50V not USA
2135 © 3198 017 32230 22nF 10% 25V USA only
2136 © 4822 126 14076 220nF 20% 25V
2137 © 4822 126 14076 220nF 20% 25V
2138 4822 124 22652 2,2µF 20% 50V
2139 © 4822 126 14236 15pF 5% 50V
2140 © 4822 126 13695 82pF 1% 63V
2141 © 4822 126 13838 100nF 10% 50V
2143 © 4822 126 14076 220nF 20% 25V
2144 4822 124 21913 1µF 20% 63V
2145 © 4822 122 33575 220pF 5% 50V
2146 © 4822 122 33575 220pF 5% 50V
2147 © 4822 122 33575 220pF 5% 50V
2148 © 4822 122 33127 2,2nF 10% 63V
2149 © 5322 122 32659 33pF 5% 50V RDS only
2150 © 4822 126 13838 100nF 10% 50V
2159 © 5322 122 31151 22µF 20% 50V
2163 © 4822 126 13838 100nF 10% 50V LW only
2164 © 4822 126 13482 470nF 20% 16V
2165 © 4822 126 13838 100nF 10% 50V
2166 © 5322 122 31647 1nF 10% 63V
2167 © 4822 122 33926 12pF 5% 50V
2169 © 4822 122 33127 2,2nF 10% 63V RDS only
2180 © 3198 017 31030 10nF 10% 50V
2190 © 4822 126 13838 100nF 10% 50V
2191 4822 124 40178 100µF 20% 10V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3105 © 4822 117 11503 220Ω 5% 0,1W
3108 © 4822 117 11449 2,2kΩ 1% 0,1W LW only
3109 © 4822 051 20472 4,7kΩ 5% 0,1W LW only
3123 © 4822 051 20472 4,7kΩ 5% 0,1W LW only
3125 © 4822 117 10833 10kΩ 1% 0,1W LW only
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3128 © 4822 117 11449 2,2kΩ 1% 0,1W LW only
3130 © 3198 021 38210 820Ω 5% 0,06W
3131 © 3198 021 38210 820Ω 5% 0,06W
3132 © 4822 051 20479 47Ω 5% 0,1W
3134 © 4822 051 20223 22kΩ 5% 0,1W
3135 © 3198 021 31020 1kΩ 5% 0,06W
3137 © 4822 051 20223 22kΩ 5% 0,1W LW only
3141 © 4822 117 11148 56kΩ 1% 0,1W
3142 4822 100 12159 TRIMPOT. 100kΩ
3143 © 4822 051 20223 22kΩ 5% 0,1W RDS only
3144 © 4822 051 10102 1kΩ 2% 0,25W RDS only
3145 © 4822 117 11449 2,2kΩ 1% 0,1W
3146 © 4822 051 20229 22Ω 5% 0,1W
3150 © 4822 117 10833 10kΩ 1% 0,1W
3151 © 4822 051 20683 68kΩ 5% 0,1W
3152 © 4822 051 20471 470Ω 5% 0,1W
3153 © 4822 051 20471 470Ω 5% 0,1W
3154 © 4822 117 13577 330Ω 1% 0,1W
3155 © 4822 117 10353 150Ω 5% 0,1W
3156 © 4822 117 10837 100kΩ 1% 0,1W
3157 © 4822 117 10837 100kΩ 1% 0,1W
3158 © 4822 051 20471 470Ω 5% 0,1W
3159 © 4822 051 20471 470Ω 5% 0,1W
3160 © 4822 051 20471 470Ω 5% 0,1W
3161 © 4822 051 20223 22kΩ 5% 0,1W
3167 © 4822 051 20121 120Ω 5% 0,1W
3168 © 4822 051 20121 120Ω 5% 0,1W
3169 © 4822 051 20154 150kΩ 5% 0,1W
3170 © 4822 117 10837 100kΩ 1% 0,1W
3171 © 4822 117 10834 47kΩ 1% 0,1W
3172 © 4822 051 20562 5,6kΩ 5% 0,1W
3176 © 4822 051 20333 33kΩ 5% 0,1W RDS only
3180 © 4822 117 10833 10kΩ 1% 0,1W LW only
3190 © 4822 051 20121 120Ω 5% 0,1W
3191 © 4822 051 20121 120Ω 5% 0,1W
3192 © 4822 117 13577 330Ω 1% 0,1W
3193 © 4822 117 13577 330Ω 1% 0,1W
3194 © 4822 117 11449 2,2kΩ 1% 0,1W
3195 © 4822 051 20101 100Ω 5% 0,1W
4101 © 4822 051 20008 CHIP JUMPER 0805 FM/AM only
4102 © 4822 051 20008 CHIP JUMPER 0805 FM/AM only
4104 © 4822 051 20008 CHIP JUMPER 0805 FM/AM only
4105 © 4822 051 20008 CHIP JUMPER 0805
4106 © 4822 051 20008 CHIP JUMPER 0805
4107 © 4822 051 20008 CHIP JUMPER 0805
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
5102 4822 157 71634 RF-COIL MW
5103 2422 549 44107 RF-COIL LW LW only
5109 4822 157 71639 FM-IF FILTER 10,7MHz
5110 4822 242 70665 FM-IF FILTER 10,7MHz
5111 2422 549 44023 AM-IF FILTER 450kHz
5112 4822 157 70302 AM-IF FILTER 450kHz
5114 4822 157 70302 AM-IF FILTER 450kHz
5115 4822 157 71636 ANTI BIRDY FILTER
5118 © 2422 535 95881 100nH
5119 4822 157 11443 DISCRIMINATOR COIL
5121 4822 242 10261 QUARTZ 75kHz
5122 2422 549 44108 RF-COIL, LW-OSCILLATOR LW only
5123 2422 549 44108 RF-COIL, MW-OSCILLATOR
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6105 © 4822 130 83075 HN1V02H
6106 © 4822 130 83757 BAS216
6107 © 9340 386 90115 BZX284-C11
6120 © 4822 130 83757 BAS216
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7103 © 5322 130 42756 BC857C RDS only
7104 9322 003 64676 TBC337-40 LW only
7105 9322 003 64676 TBC337-40 LW only
7109 © 4822 130 60373 BC856B LW only
7110 © 4822 130 60373 BC856B
7111 © 5322 130 42755 BC847C
7112 4822 130 44503 BC547C
7122 © 5322 130 42755 BC847C LW only
7124 © 5322 130 42755 BC847C LW only
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7101 4822 209 90315 TEA5762H/V1, RADIO IC
7B-4 7B-4
