MOLTIO 07 DISASSEMBLY
1/11
Remove the water tank, coffee
container and cover, drip tray, dreg
drawer, brewing unit, hot water dis-
penser.
Unscrew the screws shown.
Unhook the highlighted frame and press and lift
the top cover.
Unscrew the screws shown.
Unscrew the screws shown.
Remuve the rear pannel
Lateral panels
7.1. Outer Shell
Unscrew the screw shown and remove the
lateral panels
Left
Right
To Next Page
