Philips Saeco Moltio - 7.5. Solenoid Valve; 7.6. Pin Boiler; 7.7. Steam Pipe

MOLTIO 07 DISASSEMBLY
4/11
Loosen the screws holding the
solenoid valve to the upper plate
Moltio Automatic
and Classic
Disconnect all electrical and water
circuit connections (Moltio Milk
One Touch Carafe)
7.5. Solenoid valve
7.6. Pin boiler
Loosen the screws as illustrated and remove the boiler pin
Loosen the screws
7.7. Steam pipe
Loosen the screw.
Loosen the screws and
remove the cover evidenced.
(Moltio One Touch Milk
Carafe)
Disconnect the electrical connections.
Press to right and left and lift the
assembly KYB.
Disconnect the water circuit connection
