Philips Saeco Moltio - 7.8. Dispenser

MOLTIO 07 DISASSEMBLY
5/11
7.8. Dispenser
Disconnect the electrical connections.
Press to right and left and lift the assembly KYB.
Loosen the screws and remove the cover
evidenced. (Moltio One Touch Milk Carafe)
Loosen the screws and remove the
assembly graft milk carafe (Moltio
One Touch Milk Carafe)
Loosen the screws
Loosen the screws and remove the assembly dispenser
coffee proceeding as in the picture
Slide out the fork as illustrated
Remove the cover, loosen the screws and support teon tube
Unhook the dispenser cover
MoltioMilkOne Touch Carafe-removetheassemblygraftmilkcarafe
