ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
C517 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C518 CHIP CERAMIC CAP. B K 0.047UF/50V 111111111
C519 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C520 CHIP CERAMIC CAP. CH J 100PF/50V 111111111
C521 CHIP CERAMIC CAP. CH J 560PF/50V 111111111
C522 ELECTROLYTIC CAP. 22UF/6.3V M H7 111111111
C523 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C524 CHIP CERAMIC CAP. CH J 330PF/50V 111111111
C526 CHIP CERAMIC CAP. B K 4700PF/50V 111111111
C527 ELECTROLYTIC CAP. 22UF/6.3V M H7 111111111
C529 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C530 CERAMIC CAP.(AX) F Z 0.022UF/25V 111111111
C531 CERAMIC CAP.(AX) Y M 0.01UF/16V 111111111
C535 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C540 ELECTROLYTIC CAP. 470UF/6.3V M 111111111
C541 ELECTROLYTIC CAP. 220UF/6.3V M H7 1
C561 CHIP CERAMIC CAP. B K 0.022UF/50V 111111111
C621 CHIP CERAMIC CAP. CH J 220PF/50V 1
C622 CHIP RES.(1608) 1/10W 0 OHM 11111 111
C622 CHIP CERAMIC CAP. B K 2200PF/50V 1
C701 CHIP CERAMIC CAP. B K 0.047UF/50V 1111111 1
C702 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C703 ELECTROLYTIC CAP. 10UF/16V M H7 111111111
C704 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C706 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C707 ELECTROLYTIC CAP. 100UF/6.3V H7 111111111
C708 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C709 ELECTROLYTIC CAP. 1UF/50V M H7 1
C710 CHIP CERAMIC CAP. B K 1000PF/50V 1
C712 CHIP CERAMIC CAP. B K 0.01UF/50V 111111 1
C713 CHIP CERAMIC CAP. B K 0.01UF/50V 111111 1
C715 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C751 CHIP CERAMIC CAP. B K 2200PF/50V 111111
C752 CHIP CERAMIC CAP. B K 2200PF/50V 111111
C756 CERAMIC CAP.(AX) B K 470PF/50V 1 1 1
C757 CERAMIC CAP.(AX) B K 470PF/50V 1 1 1
C771 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C772 ELECTROLYTIC CAP. 10UF/16V M H7 111111111
C773 CERAMIC CAP.(AX) B K 1000PF/50V 111111111
C774 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C775 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C776 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C777 CERAMIC CAP.(AX) B K 180PF/50V 111111111
C778 CHIP CERAMIC CAP. CH J 180PF/50V 111111111
C851 CHIP CERAMIC CAP. CH J 22PF/50V 111111111
C852 CHIP CERAMIC CAP. CH J 18PF/50V 111111111
C853 CHIP CERAMIC CAP. B K 4700PF/50V 111111111
C854 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C855 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C856 CHIP CERAMIC CAP. CH J 180PF/50V 111111111
C858 CHIP CERAMIC CAP. CH J 560PF/50V 111111 11
C859 ELECTROLYTIC CAP. 47UF/6.3V M H7 111111111
C862 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
CN506 9965 000 12262 FNT PCB ASSEMBLY CP2500/C470/FUNCTION 1 1
CN506 9965 000 12407 FNT PCB ASSEMBLY CP2500/C480/FUNCTION 1
CN506 9965 000 13045 FNT PCB ASSEMBLY CP2500/C490/FUNCTION 1 1 1
AFV PCB
CN701 9965 000 12175 AFV PCB ASSEMBLY CP2500/C461 111111 1
CN701 9965 000 12254 AFV PCB ASSEMBLY CP2500/C463 1
DIODES
D001 4822 130 31933 RECTIFIER DIODE 1N4005 111111111
