Philips VR330/58 - Page 48

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
D002 4822 130 31933 RECTIFIER DIODE 1N4005 111111111
D003 4822 130 31933 RECTIFIER DIODE 1N4005 111111111
D004 4822 130 31933 RECTIFIER DIODE 1N4005 111111111
D005 5322 130 34979 RECTIFIER DIODE BA159 111111111
D006 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D007 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D008 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D009 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D011 4822 130 41487 RECTIFIER DIODE BA157 111111111
D012 4822 130 83883 RECTIFIER DIODE FR202 111111111
D013 4822 130 83883 RECTIFIER DIODE FR202 111111111
D014 5322 130 81917 SCHOTTKY BARRIER DIODE SB140 1
D014 4822 130 32715 SCHOTTKY BARRIER DIODE SB340 11111111
D015 4822 130 80319 ZENER DIODE MTZJT-779.1C 111111111
D018 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 111111111
D019 9965 000 05249 ZENER DIODE MTZJT-775.6B 111111111
D021 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 111111111
D051 4822 130 31933 RECTIFIER DIODE 1N4005 111111111
D052 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 111111111
D053 9965 000 12176 RECTIFIER DIODE RL201 B-222-2 111111 1
D053 4822 130 31933 RECTIFIER DIODE 1N4005 1
D053 9965 000 09322 RECTIFIER DIODE FR302 1
D056 9965 000 05694 ZENER DIODE MTZJT-775.1C 111111111
D057 4822 130 80998 ZENER DIODE MTZJT-7710B 11111111
D057 9965 000 12891 CARBON RES. 1/4W J 3.3K OHM 1
D151 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 11111111
D152 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 11111111
D153 9965 000 12178 ZENER DIODE DZ-11BSAT265 111111111
D154 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111111
D155 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111111
D156 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111111
D157 9965 000 12178 ZENER DIODE DZ-11BSAT265 1
D301 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D370 4822 130 30621 SWITCHING DIODE 1N4148M 1
D501 4822 130 30621 SWITCHING DIODE 1N4148M 111111111
D502 9965 000 05250 LED SIR-563ST3F P 111111111
D552 4822 130 10094 ZENER DIODE MTZJT-777.5A 11111111
D553 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 111111111
D621 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1
D701 4822 130 81729 ZENER DIODE MTZJT-7733D 111111111
F001
h
9965 000 12179 FUSE 21301.6M 111111111
FH001 4822 256 10461 FUSE HOLDER MSF-015 111111111
FH002 4822 256 10461 FUSE HOLDER MSF-015 111111111
FP562 9965 000 09307 LED DISPLAY LFU-4421-2001A 111111111
IC’s
IC001
h
4822 130 11655 PHOTOCOUPLER LTV-817B-F 111111111
IC301 9965 000 12180 IC:Y/C/A LA71750AM-MTB 111111111
IC370 9965 000 12255 IC:SECAM LA70100M-TRM 1
IC451 9965 000 12181 IC:HIFI LA72646M-A-MPB 11111111
IC501 9965 000 13029 MICROCONTROLLER 16BIT M37762MFA-1B8GP 11111 1
IC501 9965 000 12408 MICROCONTROLLER 16BIT M37762MFA-1B7GP 1
IC501 9965 000 12556 MICROCONTROLLER 16BIT M37762MFA-1B9GP 1 1
IC503 9965 000 06554 IC:MEMORY BR24C02F-W 1
IC503 9965 000 13030 IC:EEPROM CAT24WC04JI 1 1 1 1
IC503 9965 000 12409 IC:EEPROM M24C08-MN6T 1
IC503 9965 000 13046 IC:EEPROM M24C16-MN6T 1 1 1
IC561 9965 000 12183 IC:LED DRIVER PT6958-FN-TP 111111111
IC771 9965 000 12410 IC:COMPARATOR LM339DT 111111111
J902 4822 526 10685 BEAD CORE HF70BB3.5X10X1.3 111111111
JW001 9965 000 12411 FLAT CABLE, 11P AWG26#2651/P1.25/150 11111111
JW001 9965 000 12892 FLAT CABLE, 8P AWG26#2651/P1.25/150 1
1-16-17
