ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
JW002 9965 000 12412 FLAT CABLE, 12P AWG26#2651/P1.25/150 11111111
JW003 9965 000 12413 FLAT CABLE, 2P AWG26#2651/P1.25/120 111111111
COILS
L001 4822 526 10685 BEAD CORE HF70BB3.5X10X1.3 111111111
L002 4822 526 10685 BEAD CORE HF70BB3.5X10X1.3 111111111
L003
h
9965 000 09877 LINE FILTER 56MH TLF14CB5630R2 111111111
L009 9965 000 05627 CHOKE COIL 47UH-K 111111111
L010 9965 000 05627 CHOKE COIL 47UH-K 111111111
L012 4822 157 10649 INDUCTOR 100UH-K-26T 111111111
L251 9965 000 08652 INDUCTOR 5.6UH-K-26T 111111111
L301 4822 157 63316 INDUCTOR 56UH-K-26T 111111111
L370 PCB JUMPER D0.6-P5.0 1
L401 9965 000 05627 CHOKE COIL 47UH-K 111111111
L402 9965 000 05627 CHOKE COIL 47UH-K 111111111
L451 4822 157 10649 INDUCTOR 100UH-K-26T 11111111
L452 4822 157 10347 INDUCTOR 22UH-K-26T 11111111
L501 4822 157 10649 INDUCTOR 100UH-K-26T 111111111
L561 4822 157 10649 INDUCTOR 100UH-K-26T 11111111
L561 4822 157 11509 INDUCTOR 47UH-K-26T 1
L562 PCB JUMPER D0.6-P5.0 11111111
L562 4822 157 11509 INDUCTOR 47UH-K-26T 1
L701 4822 157 10889 INDUCTOR 10UH-K-26T 111111111
L702 9965 000 05627 CHOKE COIL 47UH-K 111111111
L703 PCB JUMPER D0.6-P5.0 1111111 1
L704 4822 157 11511 INDUCTOR 15UH-K-26T 1111111 1
L705 PCB JUMPER D0.6-P5.0 111111111
L851 9965 000 08629 INDUCTOR 1.8UH-K-26T 111111111
L853 PCB JUMPER D0.6-P5.0 111111111
PS503 9965 000 12189 PHOTO INTERRUPTER RPI-302C70 111111111
TRANSISTORS
Q001 9965 000 06568 FET FS1KM-18A 111111111
Q002 4822 130 41319 TRANSISTOR 2SC1815-BL(TPE2) 111111111
Q003 4822 130 41319 TRANSISTOR 2SC1815-BL(TPE2) 111111111
Q004 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q051 9965 000 09287 RES. BUILT-IN TRANSISTOR BN1L4M-T 111111111
Q052 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 111111111
Q053 4822 130 10103 TRANSISTOR KTC3199(Y) 11111111
Q054 9965 000 09389 TRANSISTOR 2SD1246(S) 11111111
Q054 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1
Q056 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 111111111
Q057 9965 000 12190 TRANSISTOR KTA1281(Y) 111111111
Q058 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 111111111
Q153 4822 130 10103 TRANSISTOR KTC3199(Y) 11111111
Q351 4822 130 42959 TRANSISTOR KTA1266(GR) 111111111
Q352 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q401 4822 130 42959 TRANSISTOR KTA1266(GR) 111111111
Q402 4822 130 42292 TRANSISTOR KTC3203(Y) 111111111
Q403 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 111111111
Q404 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q405 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q406 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q451 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 11111111
Q501 4822 130 10923 TRANSISTOR KTC3199(BL) 111111111
Q502 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 111111111
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 111111111
Q551 4822 130 10923 TRANSISTOR KTC3199(BL) 111111111
Q552 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 111111111
Q621 4822 130 10103 TRANSISTOR KTC3199(Y) 1
Q771 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
Q772 4822 130 10103 TRANSISTOR KTC3199(Y) 111111111
RESISTORS
