Philips VR330/58 - Page 52

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
R462 CHIP RES.(1608) 1/10W J 39K OHM 11111111
R463 CHIP RES.(1608) 1/10W J 8.2K OHM 11111111
R464 CHIP RES.(1608) 1/10W J 39K OHM 11111111
R465 CHIP RES.(1608) 1/10W J 8.2K OHM 11111111
R466 CHIP RES.(1608) 1/10W J 39K OHM 11111111
R467 CHIP RES.(1608) 1/10W J 6.8K OHM 11111111
R468 CARBON RES. 1/6W J 8.2K OHM 11111111
R469 CHIP RES.(1608) 1/10W J 6.8K OHM 11111111
R470 CHIP RES.(1608) 1/10W J 39K OHM 1 1 1
R471 CHIP RES.(1608) 1/10W J 6.8K OHM 1 1 1
R472 CHIP RES.(1608) 1/10W J 1K OHM 11111111
R473 CHIP RES.(1608) 1/10W J 1K OHM 11111111
R474 CHIP RES.(1608) 1/10W J 10K OHM 11111111
R479 CHIP RES.(1608) 1/10W J 27K OHM 11111111
R480 CHIP RES.(1608) 1/10W J 27K OHM 11111111
R501 CHIP RES.(1608) 1/10W J 1K OHM 111111111
R502 CHIP RES.(1608) 1/10W J 1K OHM 111111111
R503 CHIP RES.(1608) 1/10W J 1K OHM 111111111
R504 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R505 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R506 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R507 CHIP RES.(1608) 1/10W 0 OHM 111111111
R508 CARBON RES. 1/6W J 1K OHM 111111111
R509 CHIP RES.(1608) 1/10W J 4.7K OHM 111111111
R510 CHIP RES.(1608) 1/10W J 10K OHM 1111111 1
R511 CHIP RES.(1608) 1/10W J 100K OHM 111111111
R513 CHIP RES.(1608) 1/10W J 2.2K OHM 111111111
R514 CHIP RES.(1608) 1/10W J 820 OHM 111111111
R516 CHIP RES.(1608) 1/10W J 330K OHM 111111111
R517 CHIP RES.(1608) 1/10W J 220 OHM 111111111
R518 CHIP RES.(1608) 1/10W J 470 OHM 111111111
R519 CHIP RES.(1608) 1/10W 0 OHM 1 1 1 1 1 1
R519 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1
R520 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R521 CHIP RES.(1608) 1/10W J 220K OHM 111111111
R522 CHIP RES.(1608) 1/10W J 68K OHM 111111111
R523 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R524 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R525 CHIP RES.(1608) 1/10W J 1.5K OHM 111111111
R526 CHIP RES.(1608) 1/10W J 1.8K OHM 111111111
R527 CHIP RES.(1608) 1/10W J 680 OHM 111111111
R528 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R529 CARBON RES. 1/4W J 270 OHM 111111111
R530 CHIP RES.(1608) 1/10W J 180 OHM 111111111
R531 CHIP RES.(1608) 1/10W J 68K OHM 111111111
R533 CHIP RES.(1608) 1/10W J 33K OHM 111111111
R534 CARBON RES. 1/6W G 3.6K OHM 111111111
R535 CARBON RES. 1/6W G 10K OHM 111111111
R536 CARBON RES. 1/6W G 470 OHM 111111111
R537 CARBON RES. 1/6W G 22K OHM 111111111
R538 CARBON RES. 1/6W G 1.5K OHM 111111111
R539 CARBON RES. 1/6W G 4.7K OHM 111111111
R540 CHIP RES.(1608) 1/10W J 390K OHM 111111111
R541 CHIP RES.(1608) 1/10W J 390K OHM 111111111
R542 CHIP RES.(1608) 1/10W J 1.2K OHM 111111111
R543 CHIP RES.(1608) 1/10W 0 OHM 111111111
R544 CHIP RES.(1608) 1/10W J 1.5K OHM 111111111
R545 CHIP RES.(1608) 1/10W J 2.2K OHM 111111111
R546 CHIP RES.(1608) 1/10W J 1.8K OHM 111111111
R547 CHIP RES.(1608) 1/10W J 2.7K OHM 111111111
R551 CHIP RES.(1608) 1/10W J 100 OHM 111111111
