Philips VR330/58 - Page 53

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
R552 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R555 CHIP RES.(1608) 1/10W J 10K OHM 1 1
R556 CHIP RES.(1608) 1/10W J 10K OHM 1
R557 CHIP RES.(1608) 1/10W J 10K OHM 1 1
R558 CHIP RES.(1608) 1/10W J 10K OHM 1
R566 CHIP RES.(1608) 1/10W J 56K OHM 111111111
R601 CHIP RES.(1608) 1/10W J 10K OHM 1
R603 CHIP RES.(1608) 1/10W J 10K OHM 1
R604 CHIP RES.(1608) 1/10W J 10K OHM 11111 111
R605 CHIP RES.(1608) 1/10W J 10K OHM 1111 111
R606 CHIP RES.(1608) 1/10W J 10K OHM 1
R607 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1
R608 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1
R609 CHIP RES.(1608) 1/10W J 10K OHM 1
R610 CHIP RES.(1608) 1/10W J 10K OHM 1111 111
R612 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R613 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1
R614 CHIP RES.(1608) 1/10W J 10K OHM 11111
R615 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1
R616 CHIP RES.(1608) 1/10W J 10K OHM 1 1
R617 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1
R618 CHIP RES.(1608) 1/10W J 10K OHM 1
R621 CHIP RES.(1608) 1/10W J 100K OHM 1
R622 CHIP RES.(1608) 1/10W J 33K OHM 1
R623 CHIP RES.(1608) 1/10W J 220 OHM 1
R624 CHIP RES.(1608) 1/10W J 6.8K OHM 1
R625 CHIP RES.(1608) 1/10W J 27K OHM 1
R701 CARBON RES. 1/6W J 1.8K OHM 111111111
R702 CARBON RES. 1/6W J 1K OHM 111111111
R703 CARBON RES. 1/6W J 1K OHM 111111111
R704 CHIP RES.(1608) 1/10W J 1K OHM 111111 1
R705 CHIP RES.(1608) 1/10W J 1K OHM 111111 1
R706 CARBON RES. 1/6W J 1K OHM 111111111
R709 PCB JUMPER D0.6-P5.0 1
R751 CHIP RES.(1608) 1/10W J 1K OHM 111111
R752 CHIP RES.(1608) 1/10W J 1K OHM 111111
R756 PCB JUMPER D0.6-P5.0 1 1 1
R757 CHIP RES.(1608) 1/10W J 75 OHM 1 1 1
R758 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R759 CARBON RES. 1/6W J 4.7K OHM 1 1 1
R771 CHIP RES.(1608) 1/10W J 4.7K OHM 111111111
R772 CHIP RES.(1608) 1/10W J 100K OHM 111111111
R773 CHIP RES.(1608) 1/10W J 4.7K OHM 111111111
R774 CHIP RES.(1608) 1/10W J 22K OHM 111111111
R775 CHIP RES.(1608) 1/10W J 15K OHM 111111111
R776 CHIP RES.(1608) 1/10W J 8.2K OHM 111111111
R777 CHIP RES.(1608) 1/10W J 8.2K OHM 111111111
R778 CHIP RES.(1608) 1/10W J 33K OHM 111111111
R779 CHIP RES.(1608) 1/10W J 33K OHM 111111111
R780 CHIP RES.(1608) 1/10W J 33K OHM 111111111
R781 CHIP RES.(1608) 1/10W J 15K OHM 111111111
R782 CHIP RES.(1608) 1/10W J 33K OHM 111111111
R783 CHIP RES.(1608) 1/10W J 15K OHM 111111111
R784 CHIP RES.(1608) 1/10W J 10M OHM 111111111
R785 CHIP RES.(1608) 1/10W J 10M OHM 111111111
R786 CHIP RES.(1608) 1/10W J 2.2K OHM 111111111
R787 CHIP RES.(1608) 1/10W J 2.2K OHM 111111111
R851 CHIP RES.(1608) 1/10W J 1.5K OHM 111111111
R852 CHIP RES.(1608) 1/10W J 1K OHM 111111111
R853 CHIP RES.(1608) 1/10W J 1K OHM 111111111
RS501 9965 000 12191 REMOTE RECEIVER PIC-37042LQ 111111111
