ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
SA001
h
4822 252 11373 SURGE ABSORBER JVR-10N471K 111111111
SWITCHES
SW501 4822 276 13954 TACT SWITCH KSM0614B 111111111
SW502 4822 276 13954 TACT SWITCH KSM0614B 111111111
SW504 4822 276 13954 TACT SWITCH KSM0614B 111111111
SW505 4822 276 13954 TACT SWITCH KSM0614B 111111111
SW506 9965 000 12285 LEAF SWITCH LSA-1142AU 111111111
SW507 9965 000 09194 ROTARY MODE SWITCH R8100212 111111111
T001
h
9965 000 09203 PULSE TRANS SA-00901B 111111111
TP301 PCB JUMPER D0.6-P9.5 111111111
TP501 PCB JUMPER D0.6-P6.0 111111111
TP502 PCB JUMPER D0.6-P10.0 111111111
TP506 PCB JUMPER D0.6-P5.0 111111111
TP507 PCB JUMPER D0.6-P6.0 111111111
TP508 PCB JUMPER D0.6-P23.0 111111111
TP751 PCB JUMPER D0.6-P5.0 111111111
TU701 9965 000 13033 TUNER UNIT TMDG2-731A 111111 1
TU701 9965 000 12265 TUNER UNIT TMDG2-631A 1
TU701 9965 000 12256 TUNER UNIT TMDZ2-731A 1
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B 111111111
X301 9965 000 05629 X’TAL 4.433619MHZ 111111111
X501 9965 000 12194 X’TAL 12.000MHZ 111111111
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM) 111111111
FUNCTION CBA (MCV-B)
CN651 9965 000 09213 ANGLE PIN HEADER, 3P 6029B-1-03Z002-T 1 1 1
RESISTORS
R651 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1
R652 CHIP RES.(1608) 1/10W J 1.2K OHM 1 1 1
R653 CHIP RES.(1608) 1/10W J 1.5K OHM 1 1 1
R654 CHIP RES.(1608) 1/10W J 2.2K OHM 1 1 1
R655 CHIP RES.(1608) 1/10W J 3.9K OHM 1 1 1
SWITCHES
SW651 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW652 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW653 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW654 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW656 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
VPS CBA (MCV-C)
CAPACITORS
C640 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C642 SEMICONDUCTOR CAP. SR K 0.056UF/25V 111111111
C643 ELECTROLYTIC CAP. 4.7UF/25V M H7 111111111
C644 ELECTROLYTIC CAP. 47UF/6.3V M H7 111111111
C645 CHIP CERAMIC CAP. B K 0.01UF/50V 111111111
C648 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C649 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
IC’s
IC640 9965 000 12198 IC:VPS/PDC SLICER LC74793JM-TRM 111111111
J283 PCB JUMPER D0.6-P15.0 111111111
RESISTORS
R638 CHIP RES.(1608) 1/10W J 100 OHM 111111111
R641 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R642 CHIP RES.(1608) 1/10W J 2.7K OHM 111111111
R643 CHIP RES.(1608) 1/10W J 5.6K OHM 111111111
R644 CHIP RES.(1608) 1/10W J 10K OHM 111111111
R645 CHIP RES.(1608) 1/10W J 10K OHM 111111111
POWER SW CBA (MCV-D) 111111111
SW510 4822 276 13954 TACT SWITCH KSM0614B 111111111
JACK CBA (MCV-E) 111111111
2L022 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 111111111
A5 9965 000 12196 JACK BOARD(2-21P) HC460ED 1 1
