Philips VR330/58 - Page 55

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
A5 9965 000 12894 JACK BOARD(1-21P) HC461BD 1
A5 9965 000 12263 JACK BOARD(2-21P) HC470ED 1 1111
A5 9965 000 12273 JACK BOARD(2-21P) HC475ED 1
CAPACITORS
C101 CHIP CERAMIC CAP. B K 2200PF/50V 11111111
C102 CHIP CERAMIC CAP. B K 2200PF/50V 111111111
C103 CHIP CERAMIC CAP. CH J 470PF/50V 11111111
C104 CHIP CERAMIC CAP. CH J 470PF/50V 111111111
C105 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C107 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C108 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C109 CHIP CERAMIC CAP. B K 2200PF/50V 11111111
C110 CHIP CERAMIC CAP. B K 2200PF/50V 11111111
C111 CHIP CERAMIC CAP. CH J 470PF/50V 11111111
C112 CHIP CERAMIC CAP. CH J 470PF/50V 11111111
C113 CHIP CERAMIC CAP. B K 2200PF/50V 11111111
C115 ELECTROLYTIC CAP. 100UF/16V M H7 111111111
C116 ELECTROLYTIC CAP. 470UF/6.3V M 111111111
C117 ELECTROLYTIC CAP. 470UF/6.3V M 11111111
DIODES
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265 111111111
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111111
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265 11111111
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265 111111111
JK101 9965 000 12197 RGB CONNECTOR MRC-021V-01 111111111
JK102 9965 000 12197 RGB CONNECTOR MRC-021V-01 11111111
JK751 9965 000 13039 RCA JACK MSP-282V-12 PBSN 111111
JK756 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B 1 1 1
JK757 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B 1 1 1
JK758 9965 000 00423 RCA JACK(RED) MSP-281V3-A 1 1 1
COILS
L101 4822 526 10685 BEAD CORE HF70BB3.5X10X1.3 111111111
L121 4822 526 10685 BEAD CORE HF70BB3.5X10X1.3 11111111
TRANSISTORS
Q101 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 111111111
Q102 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 11111111
RESISTORS
R101 CARBON RES. 1/4W J 1K OHM 111111111
R102 CARBON RES. 1/4W J 1K OHM 1
R103 CARBON RES. 1/4W J 1K OHM 11111111
R104 CARBON RES. 1/6W J 4.7K OHM 11111111
R105 CARBON RES. 1/6W J 4.7K OHM 1
R106 CARBON RES. 1/6W J 4.7K OHM 111111111
R107 CHIP RES.(1608) 1/10W 0 OHM 11111 111
R108 CARBON RES. 1/4W J 68 OHM 111111111
R109 CHIP RES.(1608) 1/10W J 75 OHM 111111111
R110 CARBON RES. 1/4W J 1K OHM 11111111
R112 CARBON RES. 1/4W J 1K OHM 11111111
R113 CARBON RES. 1/6W J 4.7K OHM 11111111
R115 CARBON RES. 1/6W J 4.7K OHM 11111111
R116 CARBON RES. 1/6W J 15K OHM 11111111
R117 CHIP RES.(1608) 1/10W J 10K OHM 11111111
R118 CARBON RES. 1/4W J 68 OHM 11111111
R119 CHIP RES.(1608) 1/10W J 75 OHM 11111111
R120 CARBON RES. 1/6W J 680 OHM 111111111
R123 CHIP RES.(1608) 1/10W J 220 OHM 111111111
R125 CARBON RES. 1/6W J 680 OHM 11111111
R126 CHIP RES.(1608) 1/10W J 220 OHM 11111111
R127 CHIP RES.(1608) 1/10W 0 OHM 11111111
R128 CHIP RES.(1608) 1/10W 0 OHM 11111111
SENSOR CBA
1-16-24
