ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 111111111
Q505 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 111111111
SMV CBA
CAPACITORS
C631 ELECTROLYTIC CAP. 100UF/6.3V M 1
C632 CERAMIC CAP.(AX) F Z 0.1UF/50V 1
DIODES
D631 4822 130 30621 SWITCHING DIODE 1N4148M 1
D632 4822 130 30621 SWITCHING DIODE 1N4148M 1
D633 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 1
D634 9965 000 12177 ZENER DIODE DZ-6.8BSCT265 1
JK631 9965 000 12415 MINIATURE JACK WTJ035-10DBT 1
JW004 9965 000 12414 FLAT CABLE, 3P AWG26#2651/P1.25/150 1
TRANSISTORS
Q631 4822 130 42959 TRANSISTOR KTA1266(GR) 1
RESISTORS
R631 CARBON RES. 1/6W J 4.7K OHM 1
R632 CARBON RES. 1/6W J 2.2K OHM 1
R633 CARBON RES. 1/6W J 47K OHM 1
R634 CARBON RES. 1/6W J 1.5K OHM 1
FUNCTION CBA
FUNCTION CBA 1 1
FUNCTION CBA 1
FUNCTION CBA 1 1 1
CN651 9965 000 09213 ANGLE PIN HEADER, 3P 6029B-1-03Z002-T 111111
RESISTORS
R652 CARBON RES. 1/6W J 1K OHM 1 1 1
R653 CARBON RES. 1/6W J 1.2K OHM 1 1 1
R654 CARBON RES. 1/6W J 1.5K OHM 1 1 1
R655 CARBON RES. 1/6W J 2.2K OHM 1 1 1
R660 CARBON RES. 1/6W J 6.8K OHM 1 1 1
R662 CARBON RES. 1/6W J 1K OHM 1 1 1
R663 CARBON RES. 1/6W J 1.2K OHM 1 1 1
R668 CARBON RES. 1/6W J 3.9K OHM 1 1 1
R668 PCB JUMPER D0.6-P5.0 1 1 1
SWITCHES
SW669 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW671 4822 276 13954 TACT SWITCH KSM0614B 1 1
SW672 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW673 4822 276 13954 TACT SWITCH KSM0614B 1 1
SW674 4822 276 13954 TACT SWITCH KSM0614B 1 1
SW675 4822 276 13954 TACT SWITCH KSM0614B 1 1
SW681 4822 276 13954 TACT SWITCH KSM0614B 1
SW683 4822 276 13954 TACT SWITCH KSM0614B 1
SW684 4822 276 13954 TACT SWITCH KSM0614B 1
SW685 4822 276 13954 TACT SWITCH KSM0614B 1
SW691 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW692 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
SW694 4822 276 13954 TACT SWITCH KSM0614B 1 1 1
AFV CBA
AFV CBA 111111 1
AFV CBA 1
CAPACITORS
C1 CHIP CERAMIC CAP. F Z 0.1UF/50V 11111111
C4 CHIP CERAMIC CAP. CH J 56PF/50V 11111111
C5 CHIP CERAMIC CAP. CH J 22PF/50V 11111111
C6 CHIP CERAMIC CAP. CH J 56PF/50V 11111111
C7 CHIP CERAMIC CAP. CH D 3PF/50V 11111111
C8 CHIP CERAMIC CAP. CH D 3PF/50V 11111111
C11 CHIP CERAMIC CAP. B K 0.01UF/50V 11111111
C12 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
1-16-25
