Philips VR330/58 - Page 57

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR330/58 VR530/58 VR630/58 VR730/58 VRQ45/58 VR732/58 VR830/58 VRQ45/16 VRQ45/39
C13 CHIP CERAMIC CAP. B K 0.01UF/50V 11111111
C14 CHIP CERAMIC CAP. B K 0.01UF/50V 11111111
C15 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
C16 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
C17 CHIP CERAMIC CAP. F Z 0.1UF/50V 11111111
C19 CHIP CERAMIC CAP. F Z 0.1UF/50V 11111111
C20 ELECTROLYTIC CAP. 3.3UF/50V M H7 11111111
C21 CHIP CERAMIC CAP. F Z 0.1UF/50V 11111111
C22 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
C23 CHIP CERAMIC CAP. F Z 0.47UF/10V 1
C24 ELECTROLYTIC CAP. 0.22UF/50V M H7 11111111
CN1 4822 265 11267 ANGLE PIN HEADER, 9P 6029B-1-09Z003-T 11111111
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M 11111111
IC’s
IC1 9965 000 12199 IC:AUDIO PROCESSOR MSP3417G-QG-B8 11111111
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26T 11111111
L2 PCB JUMPER D0.6-P5.0 11111111
L3 4822 157 11318 INDUCTOR 18UH-K-26T 11111111
L4 4822 157 10889 INDUCTOR 10UH-K-26T 11111111
RESISTORS
R1 9965 000 13036 CHIP RES.(1608) 1/10W J 1K OHM 11111111
R2 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM 1
R4 9965 000 13037 CHIP RES.(1608) 1/10W J 120K OHM 11111111
R5 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM 11111111
R6 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM 11111111
R7 9965 000 09966 CHIP RES.(1608) 1/10W J 1.2K OHM 1
X1 9965 000 12200 X’TAL 18.432MHZ 11111111
