1-3-2 HG470FIS
TV screen
Note:
OSD for mechanical error will be displayed for 5 sec. after the mechanical error occurs.
When reel and capstan mechanism is not functioning
correctly
When tape loading mechanism is not functioning cor-
rectly
When cassette loading mechanism is not functioning
correctly
When the drum is not working properly
P-ON Power safety detection
EJECT R
Fig. 1
EJECT T
Fig. 2
EJECT C
Fig. 3
Fig. 4
EJECT D
EJECT P
Fig. 5
