2-1-1 U29PHSMEN
STANDARD MAINTENANCE
Service Schedule of Components
Notes:
1.Clean all parts for the tape transport (Upper Drum with Video Head / Pinch Roller / ACE Head / FE Head) using
90% lsopropyl Alcohol.
2.After cleaning the parts, do all DECK ADJUSTMENTS.
3.For the reference numbers listed above, refer to Deck Exploded Views.
* B73 ------ Recording model only
* B86 ------ Not used in 2 head model.
H: Hours : Check I: Change
Deck Periodic Service Schedule
Ref.No. Part Name 1,000 H 2,000 H 3,000 H 4,000 H
B2
Cylinder Assembly
II
B3
Loading Motor Assembly
I
B8 Pulley Assembly
II
B587
Tension Lever Assembly
II
B31
ACE Head Assembly
I
B573, B574 Reel S, Reel T
I
B37
Capstan Motor
II
B52
Cap Belt
II
*B73 FE Head
I
*B86
F Brake Assembly (HI)
II
B133
Idler Assembly (HI)
II
B410 Pinch Arm Assembly II
B414
M Brake (SP) Assembly (HI)
II
B416
M Brake (TU) Assembly (HI)
II
B525 LDG Belt II
To Next Page
