Philips VR550 - Disassembly;Assembly Procedures of Deck Mechanism

2-4-1 U29PHSDA
DISASSEMBLY/ASSEMBLY PROCEDURES
OF DECK MECHANISM
Before following the procedures described below, be sure to remove the deck assembly from the cabinet. (Refer to
CABINET DISASSEMBLY INSTRUCTIONS on page 1-7-1.)
All the following procedures, including those for adjustment and replacement of parts, should be done in Eject
mode; see the positions of [44] and [45] in Fig. DM1H on page 2-4-3. When reassembling, follow the steps in
reverse order.
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
[1] [1] Guide Holder A T DM3H 2(S-1)
[2] [1]
Cassette Holder
Assembly
TDM4H
[3] [2] Slider (SP) T DM5H (S-1A), *(L-1)
[4] [2] Slider (TU) T DM5H *(L-2)
[5] [4] Lock Lever T DM5H *(L-3), *(P-1)
[6] [2] Cassette Plate T DM5H
[7] [7] Cylinder Assembly T DM1H, DM6H Desolder, 3(S-2)
[8] [8]
Loading Motor
Assembly
TDM1H, DM7H
Desolder, LDG Belt,
2(S-3)
[9] [9] ACE Head Assembly T DM1H, DM7H (S-4)
[10] [2]
Tape Guide Arm
Assembly
T DM1H, DM8H-1 *(P-2)
[11] [10] C Door Opener T DM1H, DM8H-1 (S-4A), *(L-4)
[12] [11] Pinch Arm (B) T
DM1H, DM8H-1,
DM8H-2
*(P-3)
[13] [12]
Pinch Arm (A)
Assembly
T
DM1H, DM8H-1,
DM8H-2
[14] [14] FE Head T DM1H, DM9H (S-5)
[15] [15] Prism T DM1H, DM9H (S-6)
[16] [2] Slider Shaft T DM10H *(L-5)
[17] [16] C Drive Lever (SP) T DM10H
[18] [16] C Drive Lever (TU) T DM10H (S-7), *(P-4)
[19] [19] Capstan Motor B DM2H, DM11H 3(S-8), Cap Belt
[20]
[20]
Clutch Assembly (HI) B DM2H, DM12H (C-1)
[21] [20] Center Gear B DM12H
*[22]
[22]
F Brake Assembly (HI) B DM2H, DM12H *(L-6)
[23] [22] Worm Holder B DM2H, DM13H-1 (S-9), *(L-7), *(L-8)
[24] [22]
Pulley Assembly (HI) B DM2H, DM13H-1
[25]
[25]
Mode Gear (LM) B DM2H, DM13H-1 (C-2)
[26]
[20],[25]
Mode Lever (HI) B
DM2H, DM13H-1,
DM13H-2
(C-3)
[27]
[22],[23],
[26]
Cam Gear (A) (HI) B
DM2H, DM13H-1,
DM13H-2
(C-4)
(+)Refer to Alignment
Sec.Page 2-5-1
[28] [26]
TR Gear C B DM2H, DM13H-1 (C-5)
[29] [28]
TR Gear Spring B DM13H-1
[30] [29] TR Gear A/B B DM13H-1
[31] [31]
FF Arm (HI) B DM1H, DM13H
[32] [26]
Idler Assembly (HI) B DM1H, DM14H *(L-9)
