Philips VR550 - Electrical Parts List

NOTES:
D…..±0.5% F…..±1%
J…..±5% K…..±10%
N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MCV CB
A
111
Consists of the followin
g
MAIN CBA
(
MCV-A
)
111
JACK CBA
(
MCV-C
)
111
SENSOR CB
A
111
SENSOR CB
A
111
MAIN CBA
(
MCV-A
)
2B7 9965 000 2335
3
SHIELD ASSEMBLY HG470ED 1 1 1
2B8 9965 000 08566 BUSH, LED(F) H3700UD 1 1 1
2B46 9965 000 1217
3
ROHM HOLDER H7770J
D
111
AC001
h
9965 000 08666 AC CORD PE8B2CG1H0A-05
7
11
AC001
h
9965 000 1217
4
AC CORD PQ8B1V51H0A-05B 1
CAPACITOR
S
C002
h
9965 000 06521 METALLIZED FILM CAP. 0.068UF/250V K 1 1 1
C003
h
9965 000 2335
4
SAFTY CAP. 2200PF/250V 1 1 1
C004 4822 124 80025 ELECTROLYTIC CAP. 33UF/400V M(L.Z) 1 1 1
C005 4822 126 14142 CERAMIC CAP. B K 0.01UF/500V 1 1 1
C006 4822 126 14141 CERAMIC CAP. SL K 56PF/1KV 1 1 1
C007 CERAMIC CAP.(AX) B K 1000PF/50V 1 1 1
C008 CERAMIC CAP.(AX) X K 5600PF/16
V
111
C010 FILM CAP.(P) 0.022UF/50V J 1 1 1
C011 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C012 ELECTROLYTIC CAP. 10UF/50V M H7 1 1 1
C014 ELECTROLYTIC CAP. 470UF/35V M 1 1 1
C017 ELECTROLYTIC CAP. 470UF/16V M 1 1 1
C018 ELECTROLYTIC CAP. 100UF/16V M 1 1 1
C020 ELECTROLYTIC CAP. 1000UF/16V M 1 1 1
C021 ELECTROLYTIC CAP. 470UF/10V M 1 1 1
C025 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C026 ELECTROLYTIC CAP. 47UF/16V M H7 1 1 1
C053 ELECTROLYTIC CAP. 330UF/6.3V M H7 1 1 1
C056 CHIP CERAMIC CAP.(1608) B K 0.047UF/50V 1 1 1
C057 CHIP CERAMIC CAP.(1608) CH J 470PF/50V 1 1 1
C060 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C061 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C157 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1
C158 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1
C251 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C252 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1
C253 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1
C254 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C302 CHIP CERAMIC CAP.(1608) B K 0.022UF/50V 1 1 1
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don't degrade the safety of the product through improper servicing.
C…..±0.25
%
M…..±20%
G…..±2%
VR550/02 VR550/07 VR550/16
Parts that not assigned part numbers (-----------) are not
available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
1-16-1
