Philips VR550 - Deck Parts List

DECK PARTS LIST DECK PARTS LIST
Pos.
h
12 NC Description Pos.
h
12 NC Description
B2 9965 000 23362 CYLINDER ASS. PAL B518 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B3 9965 000 23363 LOADING MOTOR B521 9965 000 17220 REV BRAKE SPG(HI)
B8 9965 000 16631 PULLEY ASS.(HI) B522 9965 000 08483 TG POST ASS.
B9 9965 000 23364 MOVING GUIDE S P.P B525 9965 000 12230 LDG BELT
B10 9965 000 23365 MOVING GUIDE T P.P B529 9965 000 08504 CLEANER ASS.
B11 9965 000 16634 LOADING ARM(TU) B551 9965 000 17221 FF ARM(HI)
B12 9965 000 16635 LOADING ARM(SP) B553 9965 000 12233 REV SPRING
B31 9965 000 23366 AC HEAD ASS. B555 9965 000 16663 RACK ASS.
B35 9965 000 16637 TAPE GUIDE ARM ASS. B557 9965 000 23372 MOTER PULLEY U5
B37 9965 000 23367 CAPSTAN MOTOR B558 9965 000 23373 LOADING MOTOR
B52 9965 000 08593 CAP BELT B559 9965 000 16664 CLUTCH ASS.(HI)
B73 9965 000 19628 FE HEAD B562 9965 000 16665 C DRIVE LEVER(SP)
B74 9965 000 08555 PRISM B563 9965 000 16666 SLIDER SHAFT
B86 9965 000 16639 F BRAKE ASS.(HI) B564 9965 000 16667 M GEAR(HI)
B121 9965 000 16640 WORM B565 9965 000 16668 SENSOR GEAR(HI)
B126 9965 000 18128 PULLEY B567 9965 000 16669 PINCH ARM(B)
B133 9965 000 23368 IDLER ASS.(HI) B568 9965 000 16670 BT ARM
B148 4822 462 11189 TG CAP B571 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B300 9965 000 16643 C DRIVE LEVER(TU) B572 4822 532 13159 P.S.W CUT 1.6X4.0X0.5T
B303 9965 000 23369 F DOOR OPENER B573 9965 000 12241 REEL S
B313 9965 000 16645 C DRIVE SPRING B574 9965 000 12376 REEL T
B347 9965 000 08445 BRAND BADGE HC460ED B578 9965 000 12243 TR GEAR A
B354 9965 000 18130 SLIDER(TU) B579 9965 000 16671 TR GEAR B
B355 9965 000 19630 SLIDER(SP) B580 9965 000 19638 TR GEAR C
B359 9965 000 08449 CLEANER LEVER B581 9965 000 16673 CENTER GEAR
B360 9965 000 06561 CLEANER ROLLER(2) B582 9965 000 23374 TR GEAR SPRING
B361 9965 000 08450 CL POST B583 9965 000 17201 CAM WASHER
B410 9965 000 23370 PINCH ARM(A) ASS. B584 9965 000 12248 TR GEAR SHAFT
B411 9965 000 16649 PINCH SPRING B585 9965 000 13687 PSW(317505)
B414 9965 000 17218 M BRAKE(SP) ASS.(HI) B587 9965 000 16674 TENSION LEVER ASS.
B416 9965 000 16651 M BRAKE(TU) ASS.(HI) B590 9965 000 18132 BRAKE ARM(TU)
B417 9965 000 23371 TENSION SPRING B591 9965 000 17210 BAND BRAKE(TU)
B425 9965 000 08457 LOCK LEVER SPRING B592 9965 000 16678 TG POST
B482 9965 000 16653 CASSETTE PLATE L1051 9965 000 05359
SCREW, B-TIGHT
M2.6X6 PAN HEAD+
B483 9965 000 16654 LOCK LEVER L1053 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B487 9965 000 16655 BAND BRAKE(SP) L1151 9965 000 08642
SCREW, SEMS
M2.6X4 PAN HEAD+
B488 9965 000 18145 MODE LEVER(HI) L1191 9965 000 05375
SCREW, S-TIGHT
M2.6X8 WASHER HEAD+
B491 9965 000 16657 CAM GEAR(A)(HI) L1321 4822 502 14009
SCREW, S-TIGHT
M3X6 BIND HEAD+
B492 9965 000 19636 MODE GEAR(LM) L1341 9965 000 23375
SCREW, P-TIGHT
M2X6 PAN HEAD+
B494 9965 000 16659 C DOOR OPENER L1406 9965 000 08643 AC HEAD SCREW
B499 9965 000 16660 T LEVER HOLDER L1450 4822 502 14671
SCREW, SEMS
M2.6X5 PAN HEAD+
B501 9965 000 16661 WORM HOLDER L1466 9965 000 05364
SCREW, S-TIGHT
M2.6X6 BIND HEAD+
B507 9965 000 05342 REEL WASHER 5*2.1*0.5 L1467 9965 000 23376
SCREW M2.6X5
WASHER HEAD+
B508 9965 000 17219 S BRAKE SPRING(HI)
B513 4822 532 13158 P.S.W F 6*2.55*0.5
B514 9965 000 08641 SCREW RACK
B516 9965 000 05342 REEL WASHER 5*2.1*0.5
