Philips VR550 - Mechanical Parts List

MECHANICAL PARTS LIST
Pos.
h
12 NC Description
A1X 9965 000 23350 FRONT ASSEMBLY HG470ED 1
A1X 9965 000 23388 FRONT ASSEMBLY HG471BD 1 1
A2 9965 000 16612 CASE, TOP HE470ED 1 1 1
A3 9965 000 16613 CHASSIS HE470ED 1 1 1
A7 9965 000 16614 PANEL, BOTTOM HE470ED 1 1 1
A10
h LABEL, RATING HG470ED 1
A10
h LABEL, RATING HG471BD 1
A10
h LABEL, RATING HG472ED 1
A14 LABEL, BAR CODE HG470ED 1
A14 LABEL, BAR CODE HG471BD 1
A14 LABEL, BAR CODE HG472ED 1
A29 CHASSIS FOOT H79P9JD 1 1 1
1B1 DECK ASSEMBLY CZD013/VM23ED 1 1 1
2B5 9965 000 23351 SHEILD, CYLINDER HG470ED 1 1 1
2B9 CUSHION HC460ED 1 1 1
2B18 9965 000 12400 FIBER, TOP CASE HC460ED 1 1 1
2L011 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+ 1 1 1
2L012 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+ 1 1 1
2L021 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 1 1 1
2L031 4822 502 14009 SCREW, S-TIGHT M3X6 BIND HEAD+ 1 1 1
2L041 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 1 1 1
2L042 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 1 1 1
2L051 4822 502 14018 SCREW, S-TIGHT M3X5 BIND HEAD+ 1 1 1
2L099 9965 000 13027 SCREW, P-TIGHT M3X8 BIND HEAD+ 1 1 1
PACKING
S1 GIFT BOX CARTON HG470ED 1 1
S1 GIFT BOX CARTON HG471BD 1
S2 STYROFOAM HE470ED 1 1
S2 STYROFOAM(U27UK) HE471BD 1
S3 UNIT, BAG V4010PA 1 1 1
S9 AC PAD HC461BD 1
X1 9965 000 23352 REMOTE CONTROL UNIT 364/CZF29UU 1 1 1
X3 4822 320 50377 RF CORD PAL 1.2M 1 1 1
X4 ACCESSORY BAG K8092B
A
111
VR550/02 VR550/07 VR550/16
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
1-18-1
