2-4-2 U29PHSDA
(1): Follow steps in sequence. When reassembling, follow the steps in reverse order.
These numbers are also used as identification (location) No. of parts in the figures.
(2): Indicates the part to start disassembling with in order to disassemble the part in column (1).
(3): Name of the part
(4): Location of the part: T=Top B=Bottom R=Right L=Left
(5): Figure Number
(6): Identification of parts to be removed, unhooked, unlocked, released, unplugged, unclamped, or desoldered.
P=Spring, W=Washer, C=Cut Washer, S=Screw, *=Unhook, Unlock, Release, Unplug, or Desolder
e.g., 2(L-2) = two Locking Tabs (L-2).
(7): Adjustment Information for Installation
(+):Refer to Deck Exploded Views for lubrication.
.
* [ 22 ] F Brake Assembly (HI) is not used in 2 head model.
[33] [26]
BT Arm B DM2H, DM14H *(P-5)
[34] [26]
Loading Arm (SP)
Assembly
BDM2H, DM14H
(+)Refer to Alignment
Sec.Page 2-5-1
[35] [34]
Loading Arm (TU)
Assembly
BDM2H, DM14H
(+)Refer to Alignment
Sec.Page 2-5-1
[36] [16],[26]
M Brake (TU) Assembly
(HI)
TDM1H, DM15H
[37] [2],[26]
M Brake (SP) Assembly
(HI)
T DM1H, DM15H *(P-6)
[38] [37]
Tension Lever
Assembly
TDM1H, DM15H
[39] [38] T Lever Holder T DM15H *(L-10)
[40] [40]
M Gear (HI) T DM1H, DM15H (C-6)
[41] [15],[40]
Sensor Gear (HI) T DM1H, DM15H (C-7)
[42] [36],[40] Reel T T DM1H, DM15H
[43] [38] Reel S T DM1H, DM15H
[44] [34],[38]
Moving Guide S
Preparation
TDM1H, DM16H
[45] [35]
Moving Guide T
Preparation
TDM1H, DM16H
[46] [19] TG Post Assembly T DM1H, DM16H *(L-11)
[47] [27] Rack Assembly R DM17H
(+)Refer to Alignment
Sec.Page 2-5-1
[48] [47] F Door Opener R DM17H
[49] [49] Cleaner Assembly T DM1H, DM6H
[50] [49] CL Post T DM6H *(L-12)
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
↓
(6)
↓
(7)
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
To Next Page
