Phocos Any-Grid Series User Manual

www.phocos.com 53 | P a g e
AC Input Overvoltage
Category
OVC III
Low Loss AC Input Voltage
170 Vac ± 7 Vac (UPS mode)
90 Vac ± 7 Vac (Appliances mode)
See chapter “Device Operation Settings”→
“Settings menu 03”for details.
90 Vac ± 7 Vac (UPS mode)
80 Vac ± 7 Vac (App liances
mode )
See chapter “Device Operation
Settings” → “Settings menu 03”
for details.
Low Loss Return AC Input
Voltage
180 Vac ± 7 Vac (UPS mode)
100 Vac ± 7 Vac (Appliances mode)
100 Vac ± 7 Vac (UPS mode)
90 Vac ± 7 Vac (Appliances
mode )
Hig h Loss AC Input Voltage 280 Vac ± 7 Vac 140 Vac ± 7 Vac
Hig h Loss Return AC Input
Voltage
270 Vac ± 7 Vac 135 Vac ± 7 Vac
Maximum AC Input Voltage 300 Vac 150 Vac
Nominal AC Input
Frequency
50 Hz / 6 0 Hz
Low Loss Frequency 40 Hz ± 1 Hz
Low Loss Return AC Input
Frequency
42 Hz ± 1 Hz
Hig h Loss AC Input
Frequency
65 Hz ± 1 Hz
Hig h Loss Retur n AC Input
Frequency
63 Hz ± 1 Hz
Output Short Circuit
Protection
Grid mode: Circuit breaker (amperage equivalent to maximum AC input current,
resettable), Off-Grid mode: Electronic protection
Transfer Time between Grid
mode and Off-Grid mode
and vice versa
10 ms typical (UPS mode), 20 ms typical (Ap pliances mode)
Up to 50 ms when using multiple synchronized Any-Grids
See chapter “Device Operation Settings”→ “Settings menu 03” for details.
AC Output Power De-Rating
In Grid mode, the
maximum AC output power
is dependent on t he AC
input voltage.
Maximum AC
output p ower
formula when
in Grid mode:
60 Aac x AC
input voltage
= Max. AC
output p ower
Example: 60
Aac x 230 Vac
= 13,800 W
Maximum AC
output p ower
formula when
in Grid mode:
40 Aac x AC
input voltage
= Max. AC
output p ower
Example: 40
Aac x 230 Vac
= 9,200 W
Maximum AC
output p ower
formula when
in Grid mode:
30 Aac x AC
input voltage
= Max. AC
output p ower
Example: 30
Aac x 230 Vac
= 6,900 W
Maximum AC
output p ower
formula when
in Grid mode:
60 Aac x AC
input voltage =
Max. AC output
power
Example: 60
Aac x 120 Vac
= 7,200 W
Maximum AC
output p ower
formula when
in Grid mode:
38.3 Aac x AC
input voltage
= Max. AC
output power
Example: 38.3
Aac x 120 Vac
= 4,596 W
12.2 Off-Grid Mode
Model
PSW-H-
8KW-
230/48V
PSW-H-
5KW-
230/48V
PSW-H-
3KW-
230/24V
PSW-H-
5KW-
120/48V
PSW-H-
6.5KW-
120/48V
PSW-H-
3KW-
120/24V
Nominal AC Output
Power
8000 VA /
8000 W
5000 VA /
5000 W
3000 VA /
3000 W
5000 VA /
5000 W
6500 VA /
6500 W
3000 VA /
3000 W
AC Output Voltage
Waveform
Pure Sine Wave
