Phoenix Contact ELR W3 500AC I Series User Manual

21
General data ELR...-2I ELR...-9I
Power dissipation min./max. 0.88 W / 4.1 W 0.88 W / 7 W
Mains frequency 40...100 Hz
Max. switching frequency (pulse/pause times 50:50) 2 Hz
Service life 3 x 10
7
cycles
Degree of protection IP20
Ambient temperature range Operation
Transport, storage
-25°C to +70°C
-25°C to +80°C
Rated surge voltage between
Control input-, rated control supply- and switching voltage
• Mains nominal voltage (≤ 500 V AC)
• Mains nominal voltage (≤ 300 V AC,
e.g. 230/400 V AC, 277/480 V AC)
• Mains nominal voltage (300...500 V AC)
Control input voltage, rated control supply voltage and
feedback output
Feedback output and switching voltage
• Mains nominal voltage (≤ 500 V AC)
• Mains nominal voltage (≤ 300 V AC,
e.g. 230/400 V AC, 277/480 V AC)
• Mains nominal voltage (300...500 V AC)
6 kV (ELR W3-24DC/...)
safe isolation (EN 50178)
safe isolation (IEC 60947-1)
basic isolation (IEC 60947-1)
safe isolation (IEC 60947-1)
safe isolation (EN 50178)
safe isolation (IEC 60947-1)
basic isolation (IEC 60947-1)
Rated surge voltage between
Control input-, rated control supply- and switching voltage
• Mains nominal voltage (≤ 500 V AC)
Control input voltage, rated control supply voltage and
feedback output
Feedback output and switching voltage
• Mains nominal voltage (≤ 300 V AC,
e.g. 230/400 V AC, 277/480 V AC)
• Mains nominal voltage (300...500 V AC)
4 kV (ELR W3-230AC/...)
basic isolation (IEC 60947-1)
safe isolation (IEC 60947-1)
safe isolation (IEC 60947-1, EN 50178)
basic isolation (IEC 60947-1)
Surge voltage category III
Pollution degree 2
Standards/regulations
Power station requirement
IEC 60947-4-2 / IEC 61508-1 /
EN 954-1 / ISO 13849-1
DWR 1300 / ZXX01/DD/7080.8d
Coordination type 1
Mounting position vertical (horizontal DIN rail)
Mounting (refer to 8.2. Derating curves) Can be aligned with ≥ 20 mm spacing
Housing: Material
Dimensions (W / H / D)
PA 66
(22.5 / 99 / 114.5) mm
Connection data (conductor cross section)
Screw terminal blocks (solid / stranded)
M3 thread, recommended torque
See connection notes (page 15)!
0.14-2.5 mm
2
(AWG 26-14)
0.5 - 0.6 Nm / 5-7 lbs-ins
Weight approx. 212 g
Conformance / Approvals
acc. to UL 508 NLDX File: E228652
NMFT File: E323771
EU type-examination certificate in acc. with ATEX X II (2) G, X II (2) D PTB 07 ATEX 3145
Safety level see "7.1 Safe switch-off"
and "7.2 Motor Overload Protection"
6. Technical data

Phoenix Contact ELR W3 500AC I Series Specifications

General

Type	Solid-state relay
Rated Control Supply Voltage	24 V DC
Connection Method	Screw connection
Width	22.5 mm
Operating frequency	50/60 Hz
Protection class	IP20
Rated Operating Voltage	48 V AC ... 500 V AC
Operating temperature range	-25 °C to 60 °C
Storage temperature range	-40 °C to +85 °C
Relative humidity	95% (non-condensing)
Standards	IEC 60947-4-3
Input voltage	24 V DC
Output voltage	48 V AC ... 500 V AC
Output current	0.15 A ... 50 A (See derating curve)
Input voltage range	19.2 - 30 V DC
Input frequency range	47 - 63 Hz
Switching Mode	Zero voltage switch
