General| Type | Solid-state relay |
|---|---|
| Rated Control Supply Voltage | 24 V DC |
| Connection Method | Screw connection |
| Width | 22.5 mm |
| Operating frequency | 50/60 Hz |
| Protection class | IP20 |
| Rated Operating Voltage | 48 V AC ... 500 V AC |
| Operating temperature range | -25 °C to 60 °C |
| Storage temperature range | -40 °C to +85 °C |
| Relative humidity | 95% (non-condensing) |
| Standards | IEC 60947-4-3 |
| Input voltage | 24 V DC |
| Output voltage | 48 V AC ... 500 V AC |
| Output current | 0.15 A ... 50 A (See derating curve) |
| Input voltage range | 19.2 - 30 V DC |
| Input frequency range | 47 - 63 Hz |
| Switching Mode | Zero voltage switch |
