Introduction
1.4 Unpacking
Unpack the C-863 Mercury™ controller with care. Compare the contents against
the items covered by the order and against the packing list.
In C-863.10, the following components are included:
Mercury™ Controller (C-863.10)
Wide-range 15 V power supply (C-890.PS)
Power-supply line-voltage cable
RS-232 null-modem cable for PC connection (C-815.34, 3 m)
RS-232 straight-through networking cable (C-862.CN, 28 cm)
USB cable (type A to mini-B) for PC connection (14651) (EMI-suppression
ferrite no longer required)
Mercury™ Product CD with all software and manuals for Mercury™ Class
products
MS173E User Manual (this document) in printed form
If parts are missing or you notice signs of damage, contact PI immediately.
Save all packing materials in case the product need be shipped again.
1.5 Accessories
The following items are not included but can be ordered separately:
Order Number
C-815.38 Stage/motor cable, 3 m (sub-D 15 m/f)
C-862.CN2 Long straight-through networking cable for interconnecting
Mercury™ Class controllers, 180 cm
C-819.20 Analog joystick, 2 axes
C-819.20Y Y-cable for connecting 2 Mercurys™ to joystick
C-170.PB Pushbutton box with 4 buttons and 4 LEDs
C-170.IO Connector for I/O socket (p. 36), with cable, open end
C-663.PS 24 V power supply, primarily for use in systems with 24 V DC
motors not having PWM amplifiers; do not use with 12 V motors
www.pi.ws C-863 MS173E Release 1.2.7 Page 7
