Technical Data
Manual control (optional) Joystick, Y-cable for 2D-motion; pushbutton box
Miscellaneous
Operating voltage 15 to 30 VDC, 15 V recommended, if higher voltage
used, connected motor must be compatible
Current draw 80 mA + motor current (3 A max.)
Operating temperature range 5 to 50°C
Mass 0.3 kg
Dimensions 130 x 76 x 40 mm
7.2 Dimensions
Fig. 13: C-863 dimensions in millimeters
www.pi.ws C-863 MS173E Release 1.2.7 Page 34
