6 - 4
- Screw the flywheel lock tool bush on the threading
intended for the extractor.
05_132
05_131
- Fully insert the specific tool as shown in the figure
making sure that the pins perfectly fit in the holes
previously aligned, and that it is almost in contact with
the flywheel
Specific tool:
Flywheel lock tool 020472Y
- Unloose the magneto flywheel fixing nut.
- Remove the specific tool and the fixing nut.
- Remove the washer.
05_133
05_134
Flywheel and starting system
