20. Rear light
A. Tail light bulbs
B. Stop light bulbs
21. Rear right turn indicator light
22. Front left turn indicator light
23. Headlight
A. Tail light bulbs
B. High-beam light bulb
C. Low-beam light bulb
24. Front right turn indicator light
25. Engine oil pressure sensor
26. Thermistor
27. Instrument panel
A. Instrument panel lighting bulbs
B. Speedometer
C. Clock
D. Engine disabled warning light
E. Right turn indicator warning light
F. High-beam warning light
G. Fuel gauge
H. Low fuel warning light
I. Left turn indicator warning light
L. Oil warning light
M. Water temperature gauge
28. Fuel level transmitter
29. Horn
30. Horn button
31. Thermoswitch
32. Electric fan
33. Turn signal switch
34. Electric fuel pump
35. Electric pump control device
36. Spark plug
37. HV coil
VERSIONE CON TELERUTTORE DI INIBIZIONE AVVIAMENTO
Carnaby 125 - 200 Electrical system
ELE SYS - 65
