- Empty the cooling system.
- From the helmet compartment, disconnect the
coolant return pipe «A» from the water tempera-
ture thermostat. Disconnect the water temperature
sensor «B».
- Disconnect the cable «C» and the ground lead
«D» from the starter motor, disconnect the pick-up
«E» and release the cables from the clamp «F».
- Loosen the nut «G», release the throttle control
transmission from the carburettor and release the
cable harness.
- Disconnect the fuel delivery pipe «H» from the
carburettor.
Engine from vehicle Carnaby 125 - 200
ENG VE - 96
