- From the scooter left side, disconnect the con-
nector from the carburettor starter.
- From the scooter right side, disconnect the spark
plug.
- From the scooter left side, undo and remove the
engine ground screw «I»
WARNING
GET A HOIST AND BELTS TO LIFT IT.
- Place the belts on the rear part of the frame. Lift the hoist arm until the belts are tightened.
- Undo and remove the left shock absorber fixing
screw «L»
Carnaby 125 - 200 Engine from vehicle
ENG VE - 97
