- Undo and remove the nut fixing the engine on the
swinging arm «M»
- Slide off the engine pin on the swinging arm
«N». Remove the engine together with the centre
stand.
To refit the engine on the frame, carry out removal operations in reverse order, checking:
- Tightening torques (see the TORQUES table in the CHARACTERISTICS chapter).
- Secure the pipes and the cables with the corresponding clamps.
- Fill and bleed the cooling system.
- Make sure the throttle control transmission is in working order.
- Make sure the electrical devices are in working order.
Engine from vehicle Carnaby 125 - 200
ENG VE - 98
