Flywheel magneto
FLYWHEEL - FAN
Code
Action Duration
1 001109 Cooling fan - Replacement
2 001173 Rotor - Replacement
3 001067 Stator - Fitting and Refitting
4 001058 Flywheel - Replacement
Time Fly
TIME - 124
