Handlebar
Removal
Handlebars removal
Remove the handlebar cover before carrying out
this operation,.
- After removing the transmissions and discon-
necting the electrical terminals, remove the termi-
nal fixing the handlebar to the steering.
- Check all components and replace faulty parts.
N.B.
IF THE HANDLEBAR IS BEING REMOVED TO REMOVE
THE STEERING, TILT THE HANDLEBAR FORWARD TO
AVOIDING DAMAGING THE TRANSMISSIONS.
Refitting
Carry out the removal operations but in the reverse
order, observing the prescribed tightening torque.
Locking torques (N*m)
Handlebar fixing screw 50 ÷ 55
Front fork
Overhaul
Seal replacement and stanchion removal
- Remove the wheel axle.
- Remove the lower screw (1).
- Discharge the oil in the suspension.
- Remove the stem.
- Replace the sealing rings (3-4) with new ones.
- Insert the new sealing rings only after lubricating
their seatings.
- Refit the stem and the lower screw (1).
Fly Suspensions
SUSP - 95
