Tank oil
OIL RESERVOIR
Code
Action Duration
1 005018 Oil reservoir float - Replacement
2 004017 Oil reservoir - Replacement
3 004095 Oil reservoir cock - Replacement
4 004091 Oil reservoir hose - Replacement
Rear shock-absorber
Time Fly
TIME - 134
