Fuel tank
FUEL TANK
Code
Action Duration
1 004168 Fuel tank cap - Replacement
2 005010 Tank float - Replacement
3 004112 Cock-carburettor hose - Replace-
ment
4 004005 Fuel tank - Replacement
5 004007 Fuel valve - Replacement
6 004109 Fuel tank breather - change
Fly Time
TIME - 133
