Specification Desc./Quantity
12 Fuse box
13 Battery 12V - 4Ah
14 rear left turn indicator
15 Rear turn indicator bulbs Two, 12V-10W, spherical
16 Stop and tail light bulb Type: Spherical
Power: 12V 21/5W
Quantity: 1
17 Rear light assembly
18 rear right turn indicator
19 Voltage regulator
20 Mixer oil warning light control
21 Start-up remote control switch
22 Ground lead (-)
23 starter motor wire unit
24 Automatic starter
25 Carburettor heater
26 Chassis wire unit
27 Fuel level transmitter
28 front right turn indicator
29 Key switch
30 Starter button
31 Front brake stop button
32 Headlight
33 Headlight bulb 12V-35/35W
34 Front tail light bulb Type: All glass
Power: 12V 5W
Quantity: 1
35 Left turn indicator warning light 12V - 2W
36 Headlight warning light 12V 1.2W
37 High-beam warning light 12V - 1.2W
38 Instrument panel light bulbs Type: All glass
Power: 12V 1.2W
Quantity: 3
39 Low fuel warning light
40 Right turn indicator warning light 12V - 2W
41 Low oil warning light 12V - 1.2W
42 Odometer with warning lights and level indicator
Ar = Orange, Az = Sky Blue, Bi = White, Bl = Blue, Gi = Yellow, Gr = Grey, Ma = Brown, Ne = Black,
Ro = Pink, Rs = Red, Ve = Green, Vi = Purple
Conceptual diagrams
Electrical system Fly
ELE SYS - 44
